Summarization of Contents
Button Overview
Unlock Button
Press and hold to remove Fiber Twist or Blind Cover by twisting counterclockwise.
Reset Button
Recessed button to reset the device by pressing and releasing.
LED Dim Button
Press and release to dim LEDs in steps.
Port Overview
TV and LAN Ports
Ports for connecting TV and LAN devices.
Power Port and ON/OFF Button
Connection for power adapter and device power control.
LED Indicators
System LED Status
Indicates system status: OK, booting, or power off.
Uplink LED Status
Shows uplink status: link OK, establishing, or no link.
TV LED Status
Indicates TV status: OK, insufficient signal, or no TV.
Installation Guide
Box Contents and Preparation
Details on device contents, label placement, and power socket preparation.
Remove Blind Cover
Step-by-step instructions for removing the blind cover.
Remove Dust Cap
Instructions for removing the dust cap using the red string.
Connect Fiber Twist to FTU
Procedure to attach the Fiber Twist to the FTU at a 30-degree angle.
Device Connection and Safety
Connecting Cables and Power
Steps to connect TV, LAN, and power adapter, then power on the device.
Laser Safety Precautions
Warning about the Class 1 laser product and not looking directly into the connector.
Ventilation and Environment
Warning not to cover the device to ensure proper ventilation and ambient temperature limits.
