Summarization of Contents
INTRODUCTION
Initial Checklist
A preliminary list of checks to rule out common issues before hardware diagnosis.
ROOT CAUSES
Mis-adjusted or faulty belt speed sensor
Details on diagnosing and correcting issues with the belt speed sensor.
High belt/deck friction triggering overcurrent protection
Explains how friction causes overcurrent and self-protection.
Cell phone or other RF causing console glitches
Discusses interference from wireless devices affecting console performance.
Worn or damaged motor commutator/brushes or other motor failure
Covers motor wear, brush issues, and testing for motor failure.
Motor Control Board (MCB) failure
Explains MCB functions and how to test for MCB failure.
Damaged console cable/console cable too short (after incline)
Identifies issues caused by damaged or improperly routed console cables.
Loose wire connection
Addresses problems arising from loose electrical connectors.
Intermittent Emergency Stop connection
Details troubleshooting for a faulty emergency stop button connection.
Damage to rear roller
Explains how rear roller damage affects belt function and causes issues.
Low tension allowing belt slippage or drive belt damage
Covers belt tension, slippage, and drive belt condition issues.
Treadmill or panel overcurrent breaker opening
Discusses causes of circuit breaker trips related to treadmill operation.
Intermittent stuck key on console
Addresses issues with sticky or unresponsive console buttons.
Treadmill error codes
Explains common error codes like E-1, E-2, and E-b.
Treadmill issues after Software Update
Details common problems that arise post-software update.
Updating console software
Instructions on how to update the treadmill's console software.
Calibrating the speed sensor
Step-by-step guide to calibrate the speed sensor for accuracy.
Inspecting and cleaning the motor (Technician only)
Technical guide for inspecting and cleaning the treadmill motor.
