OWNER'S MANUAL
Read the TREADMILL GUIDE before using this OWNER'S MANUAL.

Advertisement

loading
Need help?

Need help?

Do you have a question about the TREAD-XP and is the answer not in the manual?

Questions and answers

Related Manuals for Horizon Fitness TREAD-XP

Summary of Contents for Horizon Fitness TREAD-XP

  • Page 1 OWNER’S MANUAL Read the TREADMILL GUIDE before using this OWNER’S MANUAL.
  • Page 2 ENGLISH English DEUTSCH NEDERLANDS FRANÇAIS ESPAÑOL Use handlebars to maintain Verwenden Sie die Gebruik het stuur om het Utilisez le guidon pour Utilice el manillar para balance when mounting and Lenkstangen, um beim evenwicht te bewaren bij het maintenir l'équilibre lors de la mantener el equilibrio al subir dismounting, and for Auf- und Absteigen das...
  • Page 3 ASSEMBLY WARNING There are several steps during the assembly process where special attention must be paid. It is very important to follow the assembly instructions and to ensure the product is assembled correctly to reduce the risk of injury. Make sure all parts are firmly tightened before using the treadmill to ensure that the treadmill is stable and structurally sound.
  • Page 4 CONSOLE SPEAKERS QUICK CONTROL WHEEL TABLET HOLDER HANDLEBAR START / STOP BUTTON SAFETY KEY PLACEMENT WATER BOTTLE HOLDER CONSOLE MAST ON/OFF SWITCH POWER CORD MOTOR COVER FOOT LATCH (UNDERNEATH DECK) RUNNING BELT/RUNNING DECK SIDE RAIL FOOT LOCK LATCH DECAL (UNDERNEATH FOOT LATCH) ROLLER END CAP TRANSPORT WHEEL REAR ROLLER...

  • Page 5: Pre-Assembly

    PRE ASSEMBLY TOOLS INCLUDED: 8 mm T-Wrench UNPACKING 6 mm L-Wrench 5 mm L-Wrench Place the treadmill carton on a level flat surface. It is recommended that you place a protective covering on your floor. Take CAUTION when handling and transporting this unit. Never open Screwdriver box when it is upside down or on its side.

  • Page 6: Assembly Step

    ASSEMBLY STEP 1 Open HARDWARE FOR STEP 1. HARDWARE FOR STEP 1 PART TYPE DESCRIPTION Insert UPRIGHT GUIDE BOLT (A) into MAIN FRAME BRACKET (1) and fully tighten. BOLT BOLT Attach LEAD WIRE to bottom end of CONSOLE ∅8 FLAT WASHER CABLE (2).
  • Page 7 ASSEMBLY STEP 2 Open HARDWARE FOR STEP 2. HARDWARE FOR STEP 2 PART TYPE DESCRIPTION Have someone help hold the CONTROL SET(7) ∅8 while attaching the CONSOLE CABLE (2). Use the ARC WASHER lead wire to carefully pull the CONSOLE CABLE (2) BOLT out of the RIGHT CONSOLE MAST (3).
  • Page 8 ASSEMBLY STEP 3 Open HARDWARE FOR STEP 3. HARDWARE FOR STEP 3 PART TYPE DESCRIPTION Carefully slide the RIGHT HANDLEBAR (8) to CONTROL SET (7) and attach by using with 3 BOLTS BOLT (E), then attach BOLT COVER (10). Repeat STEP B on the LEFT SIDE. Hook WATER BOTTLE HOLDER (11) on your ideal place on left or right Handlebar.
  • Page 9 ASSEMBLY STEP 4 Open HARDWARE FOR STEP 4. HARDWARE FOR STEP 4 PART TYPE DESCRIPTION Have someone help hold the CONSOLE ARM SET (12) BOLT while attaching the CONSOLE CABLE (13). ∅8 FLAT WASHER Carefully slide the CONSOLE ARM SET (12) to ∅8 SPRING WASHER CONTROL SET (7) and attach by using with...
  • Page 10 ASSEMBLY STEP 5 Open HARDWARE FOR STEP 5 . HARDWARE FOR STEP 5 PART TYPE DESCRIPTION Gently place the CONSOLE (16) and hook the bolt on top of the CONSOLE ARM (12). BOLT Attach the CONSOLE (16) using 4 BOLTS (F). Attach the CONSOLE ARM BACK COVER (15) using 2 BOLTS (14).
  • Page 11 ASSEMBLY STEP 6 Take the CONSOLE CONNECTION CORD (17) from the CONSOLE ARM (12) and plug into the CONSOLE (16). (Please follow the picture to plug 3 types of socket). Attach CORD COVER (18) at bottom of console. (Fix cords by gaps on cord cover). Insert the extra length of CONSOLE CONNECTION CORD (17) back to console arm is necessary.
  • Page 12 ASSEMBLY STEP 7 ASSEMBLY COMPLETE! Before the first use, lubricate the treadmill deck by following the instructions in the MAINTENANCE section in the TREADMILL GUIDE. TECH SPECS Assembled Dimensions 195 x 99 x 161 cm / (L x W x H) 77”...

  • Page 13: Treadmill Operation

    TREADMILL OPERATION This section explains how to use your treadmill’s console and programming. The BASIC OPERATION section in the TREADMILL GUIDE has instructions for the following: • LOCATION OF THE TREADMILL • USING THE SAFETY KEY • FOLDING THE TREADMILL •...
  • Page 15 CONSOLE OPERATION Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use. TOUCH SCREEN: control UI for functions. LEFT CONTROL WHEEL (INCLINE): adjust incline up & down (0.5%). RIGHT CONTROL WHEEL (SPEED): adjust speed up &...
  • Page 16 USB - A (Device Charging / Software Update) USB - C (Ethernet in) POWER BUTTON USB-C HDMI USB-A HDMI (HDMI in) USB - C USB - A HDMI POWER BUTTON • To switch to SLEEP MODE, press the power button after power on. •...
  • Page 17 MAIN PAGE & PROGRAMS SPRINT 8: 20-minute high-intensity interval training session. VIRTUAL ACTIVE: transforms ordinary exercise into breathtaking journeys through exotic locales. TRAINING: quick manual start / goal setting mode for training. ON DEMAND: workout classes powered by instructors. EXTENSION PROGRAM: reserved for new program/app...
  • Page 18 MAIN DASHBOARD 1) INCLINE ADJUSTMENT 2) HIDE DASHBOARD • Minimal: 0 km (when running belt Press the bottom small arrow to hide the is stop) • Left “ – ” button for decrease Dashboard to mini type dashboard incline level •...
  • Page 19 MAIN DASHBOARD - QUICK CONTROL MENU OF INCLINE AND SPEED 4) INCLINE ADJUSTMENT 5) SPEED ADJUSTMENT QUICK CONTROL QUICK CONTROL 1. Select the specified incline level from 1. Select the specified speed level from quick control menu. quick control menu. 2.
  • Page 20 MINI DASHBOARD 6) MINI DASHBOARD Touch the area of mini dashboard to turn back main dashboard.
  • Page 21 HOW TO SET UP THE CONSOLE • Select the desired language and time zone. • Connect to your wireless network. • Set up your Tread Lock. (depend on your equipment type) • Log into your console service account. • Check for software updates. For more details, please see below.
  • Page 22 • Tread Lock is an additional safety feature that requires a passcode to unlock the Tread-XP. • Setting up a 4-digit passcode will be required when using your Tread-XP for the first time. All users will need to enter this passcode after 45 seconds of inactivity, except during a workout or if Tread Lock is turned off.
  • Page 23 SELECTING A CLASS Tap a program on main page then tap start button. • Select sprint8 and set the level that suits you best to start a HIIT session. • Select a scenic class from Virtual Active list, the equipment will make adjustments based on the scenery along the route. •...
  • Page 24 FOLDING TREADMILLS Some treadmills have a deck that can fold for storage and transport. To fold, firmly grasp the back end of the treadmill. Carefully lift the end of the treadmill deck into the upright position until the lock latch engages and securely locks the deck into position.
  • Page 26 Horizon TREAD-XP | TREAD-XP Rev. 1.1 E | 1000481564 ©2024 Horizon Fitness...
