INSTRUCTION MANUAL
ＧＸ－Ｍ series
GX-8202M / GX-8202MD / GX-10202M / GX-12001M
GX-22001M /GX-32001M / GX-32001MD
ＧＦ－Ｍ series
GF-8202M / GF-8202MD / GF-10202M / GF-12001M
GF-22001M / GF-32001M / GF-32001MD
1WMPD4003846
- -
M M
S S
-
M
S
- -
M M
S S
-
M
S
l l
t t
i i
- -
F F
u u
n n
c c
l
t
i
-
F
u
n
c
E E
R R
E
R
E E
R R
E
R
t t
i i
o o
n n
B B
a a
t
i
o
n
B
a
I I
E E
S S
I
E
S
I I
E E
S S
I
E
S
l l
a a
n n
c c
e e
l
a
n
c
e
Advertisement
Table of Contents
Related Manuals for AND GX-32001MD
Summarization of Contents
1. Introduction
1-1 Features
Details the key features and capabilities of the GX-M/GF-M series balances.
1-2 About The Models
Describes the different models within the GX-M and GF-M series based on display and capacity.
1-3 Compliance
Discusses compliance with FCC rules regarding radio frequency energy emissions.
1-4 About Communication Manual
Directs users to download the "Communication manual" from the A&D website for communication details.
2. Unpacking The Balance
2-1 Installing The Balance
Provides step-by-step instructions for installing the balance, including leveling and connections.
3. Precautions
3-1 Before Use
Outlines essential precautions to take before operating the balance for optimal performance and safety.
3-2 During Use
Details important precautions to observe while using the balance to ensure accuracy and prevent damage.
3-3 After Use
Provides guidance on proper procedures for cleaning and maintaining the balance after use.
3-4 Power Supply
Explains precautions related to the AC adapter and power supply for safe and correct operation.
4. Display Symbols And Key Operation
4-1 Smart Range Function
Explains the Smart Range function, which uses two ranges for higher resolution and normal resolution weighing.
Key operation
Details the basic operations of the balance's keys and their functions during measurement and mode selection.
5. Weighing Units
5-1 Units
Lists available weighing units and modes, including their abbreviations and conversion factors.
5-2 Storing Units
Describes how to select and store preferred weighing units or modes in the function table.
6. Weighing
6-1 Basic Operation
Guides the user through the fundamental steps of performing a basic weighing operation on the balance.
6-2 Counting Mode (PCS)
Explains how to use the counting mode to determine the number of objects based on unit mass.
6-3 Percent Mode (%)
Details the percent mode, used for target weighing or checking sample variance against a reference mass.
6-4 Animal Weighing Mode (Hold Function)
Describes the Hold Function for weighing moving objects like animals, averaging fluctuating readings.
7. Impact Detection Function
7-1 Recording Impact History
Explains how impacts above a certain level are stored with data and time.
7-2 Output Impact History
Details methods to output the recorded impact history data via command or key operation.
8. Response Adjustment / Self Check Function
8-1 Response Adjustment
Guides on adjusting response speed and display refresh rate to stabilize weighing under environmental influences.
8-2 Self-Check-Function / Automatic Setting Of Minimum Weight Value
Explains the self-check for performance and malfunction detection, and how to set the minimum weighing value.
9. Calibration
9-1 Automatic Self Calibration For The GX-M Series
Describes the automatic self-calibration feature using internal weight, triggered by environmental changes.
9-2 One-Touch Calibration For The GX-M Series
Details the one-touch calibration process using the balance's internal mass for sensitivity adjustment.
9-3 Calibration Using An External Weight
Explains the procedure for calibrating the balance using an external weight for accurate results.
9-4 Calibration Test Using An External Weight
Describes how to test the balance's weighing accuracy using an external weight.
9-5 How to set the External Weight Value
Guides on setting the value of the external weight used for calibration or calibration tests.
9-6 Correcting The Internal Mass Value Of The GX-M series
Explains how to correct the internal mass value using an external weight.
9-7 Correcting The Internal Mass Value Of The GX-M series (Auto)
Details the automatic correction of the internal mass value based on external weight calibration.
10. Function Switch And Initialization
10-1 Permit Or Inhibit
Explains how to permit or inhibit various functions to protect parameters from unintentional changes.
10-2 Initializing The Balance
Describes the process of initializing the balance, returning parameters to factory settings.
11. Function Table
11-1 Setting The Function Table
Guides on how to navigate and set parameters within the balance's function table.
11-2 Details Of The Function Table
Provides detailed descriptions of the parameters available in the function table.
11-4 Description Of The Data Output
Directs users to the communication manual for details on data output.
11-5 Description Of The Data Format
Directs users to the communication manual for details on data formats.
11-6 Output Example Of The Data Format
Directs users to the communication manual for examples of data output formats.
11-7 Clock And Calendar Function
Explains how to set and confirm the balance's internal clock and calendar for accurate data stamping.
11-8 Comparator Function
Details the comparator function, including 3-step and 5-step comparison settings and results.
11-10 Main Display Comparison Function
Explains the main display comparison function for magnified view of comparison results.
11-11 Description Of Application
Describes different application modes like normal weighing, weighing indicator, and statistical calculation.
11-12 Outputting the function setting information
Guides on how to output the current balance function setting status for recording.
12. ID Number And GLP Report
12-1 Main Objective
Explains the purpose of ID numbers for GLP/GMP and the types of reports the balance can output.
12-2 Setting The ID Number
Details the procedure for setting or changing the balance's ID number for identification and management.
12-3 GLP Report
Explains how to output GLP/GMP reports using internal or external clock data, with examples.
13.Data Memory
13-1 Data Memory For Weighing Data
Describes storing weighing data, including ID, time, and date, up to 200 sets.
13-2 Data Memory For Calibration And Calibration Test
Explains how calibration and calibration test data can be stored, up to 50 sets.
13-3 Data Memory for Unit Mass in the Counting Mode
Details storing unit mass data for the counting mode, up to 50 sets.
13-4 Data Memory for Comparator Settings
Explains storing up to 20 sets of upper and lower limit values for comparator settings.
13-5 Data Memory for Tare Value
Describes storing up to 20 sets of tare values for quick recall and use.
13-6 Data Memory: Quick Selection Mode
Introduces the quick selection mode for recalling comparator settings or tare values from memory.
13-7 Data Memory: Confirmation and Storage Mode
Explains the mode for changing and storing recalled data like unit mass, comparator settings, or tare values.
14. Statistical Calculation Mode
14-1 How To Use The Statistical Calculation
Guides on switching to and setting up the statistical calculation mode, including selecting output items and units.
14-2 Statistical Calculation Mode (Example Of Use)
Provides an example of using the statistical calculation mode for mixing multiple formulae.
15.Flow Measurement
15-1 How To Use Flow Measurement
Explains how to enable and use the flow measurement mode, including setting flow rate units and calculation time.
16.Gross Net Tare Function
16-1 Preparation Of Gross Net Tare Function
Details the function table settings required to prepare for using the Gross Net Tare Function.
17.Minimum Weighing Warning Function
17-1 Comparing the minimum weighing value
Explains how to compare the sample amount against the set minimum weighing value and its warning displays.
17-2 Entering and outputting the minimum weighing value
Guides on setting and outputting the minimum weighing value directly or through other modes.
20.Density Measurement
Formula to obtain the density
Provides the formulas for calculating the density of solids and liquids.
(1) Prior to measurement: Changing the function table
Details function table changes needed to activate density measurement and select measurement parameters.
21.Password Lock Function
21-1 Enable Password Lock Function
Explains how to enable, disable, and set up the password lock function for balance security.
21-2 How To Input The Password At The Start Of Weighing
Guides on how to input the password when starting the balance under lock conditions.
21-3 How To Logout
Describes how to log out of the password-protected session.
21-4 Registering Password (Changing)
Details the process for registering or changing user and administrator passwords.
21-5 Changing Password
Guides on how to change an existing password for security.
21-6 How To Delete The Password (USER 01~10)
Explains how to delete user passwords, excluding administrator passwords.
21-7 Missing Password
Advises on contacting support if a password is lost or forgotten.
24.Maintenance
24-1 Treatment Of The Balance.
Provides instructions for cleaning the balance while taking precautions against dust and water ingress.
25.Troubleshooting
25-1 Checking The Balance Performance And Environment
Guides on checking balance performance and the operating environment for proper weighing.
25-2 Error Codes
Lists and explains various error codes displayed by the balance and their potential causes.
