Summarization of Contents
Introduction to Systemair Duct Fans
Product Description and Accessories
Detailed description of the circular duct fan's casing construction and optional accessories for enhanced functionality.
Intended Use of the Fan Product
Specifies the product's application for transporting clean or contaminated air and its suitability for various installation environments.
Document Scope and Authorisation
Outlines the manual's scope, covering installation, operation, and maintenance procedures performed by authorized personnel.
Product Overview: K and KV Fans
Visual identification of K and KV fan components, including numbered parts and their corresponding descriptions for clarity.
Product Identification and Specifications
Product Overview: Prio Fans
Visual identification of the prio fan components, featuring numbered parts and their corresponding descriptions for easy reference.
Understanding the Name Plate
Explanation of the information presented on the product's name plate, detailing specifications and certifications.
Fan Type Designation Details
Comprehensive table listing product names, dimensions, and motor types for K, KV, and prio fan series.
Product Liability Statement
Defines Systemair's liability limitations concerning damages arising from incorrect installation, operation, or maintenance.
Safety Guidelines and Precautions
Safety Symbol Definitions
Clarifies the meaning of warning, caution, and note symbols used throughout the manual to highlight critical information.
General Safety Instructions
Provides essential safety warnings and guidelines that must be followed before commencing any work on the product.
Required Personal Protective Equipment (PPE)
Lists the mandatory personal protective equipment (PPE) required for all personnel working on or around the product.
Product Installation Guide
Pre-Installation Checklist
Checklist of essential preparations and pre-installation checks required for safe and correct product installation.
Installing K Series Fans
Step-by-step instructions for mounting K fans on walls or ceilings using the provided mounting bracket and accessories.
Mounting Bracket Installation for K Fans
Detailed procedure for correctly attaching the mounting bracket to the K fan casing for secure installation.
Installing KV Series Fans
Instructions for installing KV fans on walls or ceilings, including the use of screws and pendulum bars or wires.
Installing Prio Series Fans
Procedure for installing prio fans in the ceiling, utilizing pendulum bars or wires for suspension and support.
Connecting Ducts to the Fan
Guidance on securely connecting air ducts to both the inlet and outlet sides of the fan product.
Electrical Connections for Systemair Fans
Pre-Connection Electrical Checks
Pre-connection checks ensuring electrical compatibility, safe environment, and correct wiring diagram adherence.
Connecting to Power Supply
Steps for completing the motor's electrical connection, including circuit breaker and residual current device (RCD) requirements.
EC Motor Speed Control
Information on utilizing a stepless 0-10 V signal for controlling EC motor speed, with specific notes on power supply usage.
EC Motor Protection
Details regarding the integrated motor protection system for EC motors and the procedure for resetting it after activation.
AC Motor Speed Control Options
Guidance on selecting compatible speed controllers for AC motors, including methods like voltage reduction and frequency converters.
AC Motor Protection Installation
Instructions for installing motor protection for AC motors, covering thermal contacts, thermistors, and protection switches.
Product Commissioning Process
Pre-Commissioning Checks
Pre-commissioning checks covering installation, electrical connections, safety devices, and air path integrity.
Step-by-Step Commissioning
Step-by-step process for commissioning the fan, including initial setup, operation checks, and gradual speed adjustment.
Operating the Systemair Fans
Starting EC Motor Fans
Procedure for initiating an EC motor using a 0-10 V signal or the integrated potentiometer for speed control.
Starting AC Motor Fans
Steps for starting an AC motor, involving the safety switch and the use of an external speed controller for operation.
Stopping the Fan Product
Instructions for safely stopping the product by setting the speed controller or the main safety switch to the OFF position.
Emergency Fan Shutdown
Procedure for immediate shutdown in emergency situations by setting the installed safety switch to the OFF position.
Maintenance and Care of Fans
Fan Maintenance Schedule
Defines the recommended maintenance intervals for the product under both usual and unusual operating conditions.
Cleaning the Fan Product
Provides important cautions and detailed instructions for safely cleaning the fan product and its internal components.
Ordering Spare Parts
Information on how to identify and obtain necessary spare parts, including contact details and order requirements.
Product Disposal Instructions
Disassembly and Disposal Procedure
Procedure for safely disassembling the product and its packaging, emphasizing recycling and adherence to disposal regulations.
Technical Data Overview
General Technical Specifications
Summary of key technical specifications such as maximum air and ambient temperatures, sound pressure, and IP class ratings.
Product Dimensions Overview
Introduction to the product dimensions section, specifying units and referencing diagrams for K, KV, and prio fans.
K Fan Dimensions
Tabulated dimensional data (ØA to H) for various K fan models, presented in millimetres for precise measurement.
KV Fan Dimensions
Tabulated dimensional data (A to H) for various KV fan models, presented in millimetres for precise measurement.
Prio Fan Dimensions
Tabulated dimensional data (A to ØL) for various prio fan models, presented in millimetres for precise measurement.
Wiring Diagrams and Schematics
AC Fan Wiring Diagrams
Wiring schematics for AC powered K, KV, and prio fans, detailing single-phase 230V connections and cable color codes.
EC Fan Wiring Diagrams
Wiring schematics for EC powered K, KV, and prio fans, covering single-phase 230V and various EC motor control interfaces.
AC Motor Speed Controller Wiring
Wiring diagrams for AC motor speed controllers including RE, REE, REU, RTRE, and FRQ5S series for diverse applications.
EC Motor Speed Controller Wiring
Wiring diagrams for EC motor speed controllers like MTP, EC-Basic, MTV, S-5EC/FRQ, and EC-Vent for advanced control.
EC Motor ON/OFF Control Wiring
Wiring diagrams illustrating ON/OFF control methods for EC motors using CO2RT-R(-D) and IR24-P models.
EC Motor Demand Control Wiring
Wiring diagrams for demand control of EC motors, covering EC Basic-T/CO2/H and EC Basic-U for variable air volume systems.
