Chapter 3: Intel ® Raid Controller Sasuc8I Characteristics; Table 1. Jumper Descriptions - Intel SASUC8I - RAID Controller Hardware User's Manual

3
Intel
Characteristics
This chapter describes the characteristics of the Intel
Figure 4
Jumper
J1
J2
J5
J6
Intel® RAID Controller SASUC8I Hardware User's Guide
®
RAID Controller SASUC8I
displays the connectors and headers on the controller and

Table 1. Jumper Descriptions

Description
PCI Express* x8
lane board edge
connector
Internal SAS/SATA SFF8087
port connector,
ports 4-7
Internal SAS/SATA SFF8087
port connector,
ports 0-3
Right angle, 0.1- 4-pin
inch pitch, pin header
header
®
Figure 4. Card Layout
Type
Connection to SAS/SATA devices
Connection to SAS/SATA devices
For driving external activity LEDs
RAID Controller SASUC8I.
Table 1 describes them.
s
Comments
