Troubleshooting
Out of focus
Use the following procedure to adjust the
focus.
1. Set both the pan and tilt positions to
zero (0) degrees.
2. Remove the lens cover.
3. Loosen the screws fastening the lens
block.
Caution: For safety, turn off the power
before loosening the lens block
screws.
4. Display an VN-C2WU image with the
WWW browser software. (Animated
images can be displayed with the
WWW browser software.)
5. Slowly rotate the lens block until the
focus is correct.
6. Tighten the lens block screws.
7. Firmly attach the lens cover, making
sure the cutouts in the lens cover and
case are aligned.
Lens block
Mount so that the notches
are aligned
Lens cover
Lock screw
26
