V.NETWORKS
VN-C2WU
INSTRUCTIONS
Thank you for purchasing the JVC VN-C2WU.
To gain maximum benefit from this product, read this
instruction manual carefully before use and retain it for future
reference.
The serial number is very important for maintaining quality of
your product. At the time of purchase, check to see that the
serial number is correctly printed on the top of the unit and
that the serial numbers on the unit and warranty match.
This instruction manual is printed on
recycled paper.
For Customer Use:
Enter below the Model No. and Serial
No. which are located on the rear of the
cabinet. Retain this information for future
reference.
Model No.
Serial No.
SS961534-001

Advertisement

Table of Contents
loading

  Related Manuals for JVC VN-C2WU - V-networks Pan/tilt Camera

  Summary of Contents for JVC VN-C2WU - V-networks Pan/tilt Camera

  • Page 1 VN-C2WU This instruction manual is printed on INSTRUCTIONS recycled paper. Thank you for purchasing the JVC VN-C2WU. For Customer Use: To gain maximum benefit from this product, read this Enter below the Model No. and Serial instruction manual carefully before use and retain it for future No.
  • Page 3: Table Of Contents

    CONTENTS Safety Precautions ....................i Package Contents ....................1 Operating Environment ..................1 VN-C2WU Installation and Setup ................3 Before starting installation and setup ..............3 Names of VN-C2WU parts .................. 3 Installation and setup ..................4 Installation ......................4 Connecting to a network ..................
  • Page 4: Package Contents

    Package Contents This product includes all of the following items. If any item should be missing, please contact your local dealer. VN-C2WU main unit Ferrite core Instruction manual (this document) Operating Environment The environment described below is necessary for operation of the VN-C2WU. A personal computer running the following WWW browser software: WWW browser software that is compatible with JavaScript or Frame.
  • Page 5: To Ensure Correct Usage

    To ensure correct usage When installing, avoid the following. • Locations subject to rain and water. • Locations where the ambient temperature exceeds the range of 0 to +40 °C. • Locations with vibration. • Locations with excessive dust, oil or gas. When this product is used with AGC on (camera setting: Auto), sensitivity will be increased automatically in dark places and the screen may flicker in some cases.
  • Page 6: Vn-C2Wu Installation And Setup

    VN-C2WU Installation and Setup Before starting installation and setup It is necessary to set an IP address for each VN-C2WU unit. Use the following procedure for the setup of individual units. (If the power is not turned on, the installation operation can be performed at one time.) 1.
  • Page 7: Installation And Setup

    Installation and Setup 1. Installation Use the optional bracket for installation. Make the power and network connections after completion of the installation. Caution To prevent the unit from falling, mount only on areas with sufficient strength. VN-C2WU can be installed as shown in the diagram below, or inverted. Do not install the unit sideways.
  • Page 8: Connecting To A Network

    2. Connecting to a network (Ethernet, Fast Ethernet through Auto negotiation HUB). Turn on the power of only one VN-C2WU unit. When network connection is completed and the power is turned on, the VN-C2WU unit will be connected to the network at the following IP address. Factory set (Default) IP address : 192.168.
  • Page 9: Setting The Vn-C2Wu Ip Address

    3. Setting the VN-C2WU IP address 3-1 Changing the IP address of the PC Display the network settings panel by selecting Settings from the Start button, then selecting Control Panel and Network, in that order. (1) Select the TCP/IP item, then click on Properties.
  • Page 10: About The Web Pages Mentioned In This

    About the web pages mentioned in this instruction manual From the following page, all the screens expressed as VN-C2WU pgae are contained in VN-C2WU and displayed by the web page browse and display function of the WWW browser software. Therefore depending on WWW browser software and its settings, the formats and fonts may be different from the screens of VN-C2WU page, in this manual.
  • Page 11 3-2 Changing internal settings Start the WWW browser software. Specify the factory-set VN-C2WU web page address in the browse location in the WWW browser software. (When the factory-set IP address is specified, the WWW browser software will display the VN-C2WU top page.) http://192.168.0.2/ Caution Caution...
  • Page 12 Display of the VN-C2WU top page. VN-C2WU top page. Click on Settings. The Settings page is displayed. VN-C2WU Settings page. Scroll so that all of "Other Settings" can be seen.
  • Page 13 Setup is performed by changing the "Other Settings" contents. VN-C2WU Settings page "Other settings" Other Settings [IP address] Change to an IP address assigned or approved by the network administrator. [Subnet mask] Like the IP address, the subnet mask is assigned or approved by the network administrator. [Default Gateway] Set the default Gateway IP address.
  • Page 14 Other Settings [Program version] The version of the VN-C2WU main unit firmware. Cannot be changed. [Power Frequency] This setting reduces the amount of flicker under fluorescent lighting. Set to 50Hz or 60Hz in accordance with the power frequency at the installation location. [Password] Specify using up to 8 letters.
  • Page 15 VN-C2WU Settings page "Other Settings" Press Apply button to enable the setting. Check the new IP address again. If there is no mistake in the entry, click on OK. Caution Caution The confirmation screen shown above will appear when the IP address, subnet mask, host name and power frequency settings are changed.
  • Page 16 3-3 Restore to the original PC IP address Using the same procedure as described in item 3-1, select Settings from the Start button, then select Control Panel and Network, in that order. Next, restore to the original IP address and reboot the PC in accordance with the messages.
  • Page 17 Enter the User Name and Password. Enter a password. It is not necessary to enter a user name. Click on OK. In order to assure quick display of the VN-C2WU web page from the WWW browser being used, register a browse location (URL : Uniform Resource Locator) is recommended. Use Bookmarks with Netscape or Favovites with Internet Explorer for this registration.
  • Page 18: Vn-C2Wu/Web

    VN-C2WU/Web page Explanation of display items and operations The following is a diagram of the configuration of the VN- C2WU internal URL (web pages). Caution In order to access all the VN-C2WU web pages, the Administrator level password is required. Password level USER OPERATOR...
  • Page 19: Still Image Page

    Still image page: http:// ***** still_e.html. ( ***** is the URL of the VN-C2WU) This page is to display a still image when browsing is started. To update the image, use the Reload or Refresh function of the WWW browser software. To save the image being displayed, use the Save as...
  • Page 20: Control Page

    Control page: The URL will be changed automatically by the WWW browser software. Netscape http:// ***** /spushcontrol_e.html Internet Explorer http:// ***** /javacontrol_e.html. ( ***** is the URL of the UN-C2WU) This page is to control Pan/Tilt operations and to operate the position memory. The images are updated automatically and displayed as live images.
  • Page 21 Pan/Tilt control The current Pan/Tilt angle step is displayed here. Angles (integer value) can be changed by entering value and clicking on the Apply button. VN-C2WU control page VN-C2WU control page The Pan/Tilt can be controlled with the 8 Pan/Tilt operation buttons.
  • Page 22: Position Memory Setting

    Position memory movement The VN-C2WU is equipped with 10 position memories. VN-C2WU control page (position memory control) VN-C2WU control page (position memory control) Position memory setting The contents of the currently set position memory are displayed. VN-C2WU control page (position memory setting) VN-C2WU control page (position memory setting) The current Pan/Tilt position can be set to any of the 10 position memories by clicking on "Apply".
  • Page 23: Setting Page

    Settings Page: The URL will be changed automatically by the WWW browser software. Netscape http:// ***** /spushconfig_e.html Internet Explorer http:// ***** /javaconfig_e.html. ( ***** is the URL of the VN-C2WU) This page is to make the camera image related settings and connection (setup) related settings. (The images are updated automatically and displayed as live images.) VN-C2WU settings page Hyper link to other pages...
  • Page 24: Image Quality Setting

    Camera Auto/Manual Settings VN-C2WU settings page (Auto/manual settings) Manual : “Quality” in “Image Quality Setting” such as Saturation and Color Balance can be manually set. Auto : “Quality” in “Image Quality Setting” can be automatically set. Select Auto or Manual depending on operational environment.
  • Page 25 Image Quality menu [Resolution] Three different image sizes are available: 640 x 480, 320 x 240 and 160 x 120. [Compression Rate] The compression ratio has an inversely proportional relationship to image quality but increasing the compression ratio increases the number of frames that can be displayed per second. Compression ratio Medium High...
  • Page 26 Item Effect Saturation Adjustment of the color saturation. Also effective when Auto is set. (The larger the setting value, the greater the color saturation.) Color Balance Adjustment of the tone. Also effective when Auto is set. (50 is the median value. Decreasing the setting value emphasizes red and increasing the setting value emphasizes blue.) Adjustment of the image brightness.
  • Page 27: How To Link The Vn-C2Wu Images

    How to link the VN-C2WU images The still or live mages of VN-C2WU can be pasted and displayed in a separate web page you have created. Displaying still image: A still image can be displayed by creating a web page with the contents described below. <IMG SRC="http:// ***** /still.jpg">...
  • Page 28 Displaying with Java Live images can be displayed with Java-compatible WWW browser software (Internet Explorer, etc.) by creating a web page with the contents described below. <APPLET CODE="mjpeg.class"WIDTH=640 HEIGHT=480> CodeBase=http:// ***** /"></APPLET> ***** indicates the VU-C2WU IP address. Caution Caution The resolution, compression rate, etc., of both the still and live images browsed and displayed (in a separate web page are) in accordance with the previously set setting values.
  • Page 29: Troubleshooting

    Troubleshooting Out of focus Use the following procedure to adjust the focus. 1. Set both the pan and tilt positions to zero (0) degrees. 2. Remove the lens cover. 3. Loosen the screws fastening the lens block. Caution: For safety, turn off the power before loosening the lens block screws.
  • Page 30 The new VN-C2WU IP address Unknown IP addresses are handled as re- has been forgotten. coveries or repairs. Contact your local deal- The password set with the pass- Cancellation of the password protection word protection function has function is handled as a repair, so contact been forgotten.
  • Page 31 The colors are unsatisfactory. • Try changing Camera Auto/Manual Setting on the VN-C2WU Setting Page from Auto to Manual and then back to Auto. When using a different light sources for re- cording (For example, when moving back and forth between outdoors under sunlight and in- doors under fluorescent lighting.) In some cases, time is required for the...
  • Page 32: Specifications

    Specifications LAN standard : IEEE 802. 3 standard Communication protocol : TCP/IP, HTTP Image sensor : 1/3 inch, 300,000 pixels CMOS image sensor Minimum focusing distance : 1.0 m Pan/Tilt angles : Pan : 100° Tilt : 80° Output image format : 640 X 480, 320 X 240, 160 X 120 pixels Power voltage : DC 5 V...
  • Page 33 VICTOR COMPANY OF JAPAN, LIMITED Printed in Japan SS961534-001 COPYRIGHT © 2000 VICTOR COMPANY OF JAPAN, LTD.
