ROSE DISPLAYS GOTCHA WITH LOOP TO LOOP Instruction Sheet

Advertisement

Gotcha
Parts

Instructions For Hanging

Step 1

Place poster on a flat surface. Snap the Gotcha
Holder open and insert poster (top and bottom).
To close, snap the Gotcha Holder shut. Fig. 1
Note: It is easier to open and close the Gotcha
Holder by starting at one end and working your
way down the holder.

Step 2

Thread loop through V-clip. Fig. 2

Step 3

Thread the other loop through the One Up
Gotcha Clip. Insert the One Up Gotcha Clip
into the backside of the Gotcha. You should hear
a "SNAP" when the clips are inserted properly.
If you are hanging a one-up application you will
use only one clip. Fig. 3

Step 4

Squeeze the V-clip onto the ceiling grid
to suspend poster.

Important note:

Please save and reuse the Gotcha Holder, V Clip,
Loop to Loop Cable and the OneUp Gotcha
Clips for future projects.
The Gotcha
®
is a registered trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products. Part #00INSGO
Incept-7.16.01
®
Instruction Sheet
OneUp Gotcha Clip
Gotcha
12G100
Loop to Loop
1UP-5066
Figure 1
Cables
Figure 2
Figure 3
35 Congress Street, Salem MA 01970
Tel# 1-800-631-9707 Fax# 1-800-560-2890
e-mail:signware@rosedisplays.com
V Clip
25-0394
