ROSE DISPLAYS GOTCHA WITH FISH CLIP Instruction Sheet

Gotcha

Parts

Gotcha
12G100

Instructions for Hanging

Instructions for Hanging

Step 1

Place poster on a flat surface. Snap the Gotcha
Holder open and insert poster top. To close, snap
the Gotcha shut. Fig. 1
Note: It is easier to open and close the Gotcha
Holder by starting at one end and working your
way down the holder.

Step 2

Gently squeeze back of SlimSqueeze holder to ease
insertion of graphic. Insert poster bottom working
down length of holder. Fig 2.

Step 3

Attach one end of the Jack Chain into a Gotcha
Clip, repeat. Insert Gotcha Clips into slot on the
backside of the top Gotcha Holder only. (You
should hear a "SNAP" when the clips are inserted
properly). Fig. 3
Note: For best results, place the clips 1/3 of the
way in from each end on the top Gotcha Holder.

Step 4

Attach the other end of the Jack Chain to Fish
Clip. Attach Fish Clip to ceiling grid. Fig. 3

Important note:

Please save and reuse the Gotcha Holder, Fish
Clips, Gotcha Clips, SlimSqueeze and Jack Chain
for future projects.
Gotcha® and SlimSqueeze® are registered trademarks of Rose Displays,
Ltd. Neither the manufacturer nor any sales agent may be held liable for
injury, loss or damage resulting from the use of these products.
Part #99INSGOFCLP
Incept-4.4.99
®
Instruction Sheet
Gotcha Clip
12G100
SlimSqueeze
Fish Clip
12i300
25-0360
Figure 1
Gently pinch
holder open
Figure 2
Figure 3
Jack Chain
40-0028
Insert poster starting
at one corner
Figure 3
