AnoMulti™

Parts

Instructions for Hanging

Step 1

Insert the poster into the Slim Holder by either
sliding the poster into the holder or tapping the
holder onto the poster. . Fig. 1
Note: For thinner substrates, it may be neces-
sary to staple the edge of the graphic before
inserting into Slim Holder.

Step 2

Slide Slim holder into AnoMulti holder. Fig. 2

Step 3

Squeeze sides of MultiClip together. Fig.3

Step 4

Align the bottom rail of the MultiClip with
the top channel of the aluminum holder. Slide
MultiClip into rail. Fig. 4 Repeat steps 3 & 4
for second MultiClip.

Step 5

Push end caps into place. Fig. 5

Step 6

Suspend poster. Fig. 6

Important note:

Please save and reuse the AnoMulti holder,
End caps and MultiClips for future projects.
The AnoMulti™ and Slim™ are trademarks of Rose Displays, Ltd.
Neither the manufacturer nor any sales agent may be held liable for
injury, loss or damage resulting from the use of these products.
Part #02INSAnoMultiMC
Incept-7.31.02
Instruction Sheet
AnoMulti
12AM300R
MultiClips
1UP-0101
Figure 1
Figure 3
Figure 5
End Caps
06-5525
Figure 4
Figure 6
35 Congress Street, Salem, MA 01970
Tel# 1- 800 631-9707 Fax# 1-800-560-2890
e-mail:signware@rosedisplays.com
Figure 2
