ROSE DISPLAYS ANOSCREEN WITH BASE RAIL Manual

AnoScreen™
Parts
Ano rails

Instructions For Assembly

Step 1

Insert corner brackets into ends of
bottom base rails, using thumb, as
shown in illustration. 2 brackets per
end of each rail. Fig. 1
Detail Fig. 1a- Corner bracket tension
tabs face toward outside of frame.

Step 2

Lay out parts as they will be configured
on the floor. (2, 3 or 4 panels)

Step 3

Assemble the vertical rail assemblies
onto the upward facing corner brackets
already inserted into the bottom base
rails. All 4 brackets can go into the
vertical rails at one time, or you can do
one side at a time.
Note: Make sure grommets are on the
top end of the vertical panels. Use the
two vertical rails without flex spine
connectors on the outside edges of the
outermost panels.
The AnoScreen™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part#02INSAnoScreenBaseRail
Incept-8.15.02
Instruction Sheet
Base Rails
Corner Brackets
1
2
3
3
Vertical Rails
with Flex Spine
1a
3
2a
2 Panel
3 Panel
4 Panel
(continued on other side)
