ROSE DISPLAYS ANOMULTI ROUND WITH CABLE AND SAUCER Instruction Sheet

Advertisement

AnoMulti™

Parts

Instructions For Hanging

Step 1

Insert the poster into the Slim Holder by either
sliding the poster into the holder or tapping the
holder onto the poster. . Fig. 1
Note: For thinner substrates, it may be neces-
sary to staple the edge of the graphic before
inserting into Slim Holder.

Step 2

Slide Slim Holder into the AnoQuick Holder.
Fig. 2

Step 3

Insert saucer into end of top Ano rail. Fig. 3.
Note: It is easier to slide the saucer in the Ano rail
if you hold the cable as close to the saucer as
possible.

Step 4

Push end caps into place. Fig. 4

Step 5

Suspend poster.

Important note:

Please save and reuse the AnoMulti Holder,
End caps and Cable and Saucer for future projects.
The AnoMulti and SlimSqueeze are registered trademarks of Rose
Displays, Ltd. Neither the manufacturer nor any sales agent may be held
liable for injury, loss or damage resulting from the use of these products.
Part #02INSAnoMCableSaucer
Incept-8.23.02
Instruction Sheet
Cable and
AnoMulti
12AM300
16-0018SS
Saucer
End Caps
06-5525
Figure 1
Figure 2
Figure 3
Figure 4
35 Congress Street, Salem MA 01970
Tel# 1-800-631-9707 Fax# 1-800-560-2890
e-mail:signware@rosedisplays.com
