AnoGotcha™ Frame

Parts

Instructions for Hanging

Step 1

Install four (4) corner brackets (2 each
end) into solid rail opposite split rails.
Fig. 1

Step 2

Push remaining solid rails onto rail
from Step 1 to make three (3) sides
of the frame. Fig. 2

Step 3

Slide Gotcha into top and bottom
rails as shown. Fig. 3 & 4

Step 4

Install remaining corner brackets into
ends of split rails. Fig. 5

Step 5

Assemble split rails onto frame one
at a time. Fig. 6
™
AnoGotcha is a trademark of Rose Displays, Ltd. Neither the manufac-
turer nor any sales agent may be held liable for injury, loss or damage
resulting from the use of these products. Part #02INSAnoGotchaFrame
Incept-9.9.02
AnoGotcha
Solid Rails
12AG400 T-Top Gotcha
Figure 1
Figure 3
Figure 5
Instruction Sheet
Split Rails
Figure 2
Figure 4
Figure 6
Continued on next page
35 Congress Street, Salem, MA 01970
Tel# 1- 800 631-9707 Fax# 1-800-560-2890
e-mail:signware@rosedisplays.com
Corner
brackets
