ROSE DISPLAYS ANOGOTCHA PLUS WITH MULTICLIPS Manual

AnoGotcha Plus

Parts

Instructions to hang graphic

Step 1

Place poster on a flat surface. Snap the Gotcha
holder open so hinge is turned up as far as possible.
Insert graphic completely into holder until edge of
graphic meets top of holder. Fig. 1 To close, snap
the Gotcha holder shut. Fig. 2
Note: It is easier to open and close the Gotcha
holder by starting at one end and working your way
down the holder. With large or curling graphics, it
may be easier to insert graphic at one end and slide
into holder from one end to another.

Step 2

Insert Gotcha into AnoGotcha Plus Shell. Fig 3

Step 3

Squeeze sides of MultiClip together. Fig. 4
Align the bottom rail of the MultiClip with the top
channel of the aluminum holder. Slide MultiClip
into rail. Fig. 5

Step 4

Push end caps into place. Fig 6

To Change Graphic:

Rotate one end cap on each AnoGotcha Plus 180˚
and slide out Gotcha. Fig. 7 Repeat steps 1 and 2.
Insert Gotcha back into the AnoGotcha Plus and
rotate the end cap back into position.
AnoGotcha is a traemark and Gotcha is a registered trademark and Ano
is a registered trademark of Rose Displays, Ltd. Neither the manufacturer
nor any sales agent may be held liable for injury, loss or damage resulting
from the use of these products.
Part #04INSAnoGotchaPlus
Incept-2.15.05
AnoGotcha Gotcha holder
Plus Shells
12AG500
Instruction Sheet
Another quality product from Rose Displays' Ano® line of products.
MultiClips
Figure 1
Figure 4
Figure 6
Figure 2
Figure 3
Figure 5
Figure 7
