AnoFrame™ Slatwall Hanger

Parts

Instructions for Hanging

Instructions for Hanging

Step 1

Insert hangers into upper portion
of slatwall. Fig. 1
Note: To ensure that the frame hangs level use
two hangers placed an equal distance in from
each side of the frame.

Step 2

Hangers will rest on lower portion
of slatwall. Fig. 2

Step 3

Place the AnoFrame on the hangers using the
bottom channel of the top Ano rail. Fig. 3

Step 4

AnoFrame in position on slatwall. Fig. 4
The AnoFrame™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss
or damage resulting from the use of these products.
Part #02INSAnoFrameAssembledSlatwall
Incept-9.6.02
AnoFrame Slatwall Hanger
12AF-100
Instruction Sheet
06-6068
Figure 1
Figure 3
35 Congress Street, Salem MA 01970
Tel# 1-800-631-9707 Fax# 1-800-560-2890
Figure 2
Figure 4
