ROSE DISPLAYS ANOFRAME ROUND NO LOAD WITH MULTICLIPS Manual

AnoFrame
Parts

Instructions For Assembly

Step 1
Insert corner brackets into vertical
AnoFrame side rails. Fig. 1 & Fig.2
Note: Assembly brackets tension
tabs face towards outside of frames.
Step 2
Install MultiClips in top frame rail.
Holding clip at slight angle, first insert
one round end, then press down on
other round end and push MultiClip
into rail. Fig 2
Step 3
Push top and bottom horizonral Ano
rails onto one side rail as shown in Fig.
3.
Step 4
Insert poster through side opening.
Fig 4
Step 5
Push final side rail into place as shown
in Fig 5. Suspend poster.
Note: The AnoFrame shown here is
a round profile. It is available in
either round or square profile.
The AnoFrame is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss
or damage resulting from the use of these products.
Part #02INSANFRNoLoad
Incept-8.15.02
TM
Round Profile Instruction Sheet
Corner
Brackets
AnoFrame Rails
12AF-100
Figure 1
top horizontal rail w/MultiClips
horizontal rail
Figure 3
Figure 5
MultiClips
1UP-0100
Figure 2
Figure 4
