Summarization of Contents
NZXT Kraken X RGB Series Components
A. Kraken X53 / X63 / X73
The main liquid cooler unit, including the radiator and tubing.
B. Intel Retention Bracket (Pre-Installed)
Pre-installed bracket for Intel CPUs, used for mounting the pump assembly.
C. AMD Retention Bracket
Retention bracket designed for mounting the pump onto AMD CPU sockets.
D. Intel Backplate
Backplate that attaches to the rear of the motherboard for Intel CPU installations.
E. Intel Socket 1200/115X/1366 Standoff
Standoffs specifically designed for Intel LGA 1200, 115X, and 1366 sockets.
F. Intel Socket 2011/2066 Standoff
Standoffs designed for Intel LGA 2011 and 2066 sockets.
G. AMD Standoff (AM4)
Standoffs provided for AMD AM4 socket installations.
H. Thumbscrew
Fasteners used to securely attach the pump assembly to the standoffs.
I. 30MM UNC 6-32 Fan Screw
Screws used for mounting fans to the radiator or PC case.
J. 5MM UNC 6-32 Screw
Shorter screws used for mounting the radiator directly to the PC case.
K. Washer
Washers included to protect surfaces and ensure secure component mounting.
L. Aer RGB Fan
High-performance RGB fans compatible with the Kraken cooler.
M. Breakout Cable Set
Cables that connect the pump, fans, and RGB lighting to the motherboard.
N. Micro-USB Cable
Cable to connect the pump to a motherboard USB 2.0 header for software control.
O. Fan Splitter Cable
Allows multiple fan power connections to a single motherboard header.
P. 500MM Fan Connection Cable
Cable used to connect fans to the breakout cable or fan splitter.
Q. 100MM Fan-to-fan Cable
Cable used to connect Aer RGB fans in a series.
Preparation for Installation
2.1 Preparation - Intel LGA 1200/115X/1366
Steps for preparing the backplate and installing standoffs for Intel LGA 1200/115X/1366 sockets.
2.2 Preparation - Intel LGA 2011/2066
Steps for preparing the backplate and installing standoffs for Intel LGA 2011/2066 sockets.
2.3 Preparation - AMD
Steps for preparing the retention bracket and installing standoffs for AMD sockets.
Installation Guide
3.1 Installing the Pump - Pump Orientation
How to orient the pump cap by rotating its upper section for optimal tube placement.
3.2 Installing the Pump - Intel/AMD AM4
Instructions for mounting the pump assembly onto the CPU using standoffs and thumb nuts.
3.3 Installing the Pump - AMD TR4
Guidance on aligning and tightening screws for the pump with the AMD TR4 retention bracket.
3.4 Mounting the Radiator and Fans
Instructions for attaching the radiator and fans to the PC case using appropriate screws.
3.5 Powering the Fans
Connecting the fans to the motherboard or fan controller via splitter cables.
3.6 Connecting the Pump Tach
Connecting the pump's tachometer signal to the motherboard's CPU_FAN header.
3.7 Connecting the SATA Power Cable
Supplying power to the cooler by connecting the SATA power cable from the PSU.
3.8 Connecting the USB Cable
Connecting the pump to a motherboard USB 2.0 header for software control.
3.9 Connecting RGB LED for lighting control
Connecting NZXT RGB devices to the breakout cable for lighting customization.
3.10 Connecting the Aer RGB Fans
Connecting the Aer RGB 2 fans to the cooler and linking them in series.
Appendix and Support
5.1 NZXT Global Warranty Policy
Details NZXT's global warranty terms, coverage, limitations, and service procedures.
5.2 Support and Service
Contact information and procedures for obtaining technical support and replacement parts.
5.3 Regulatory Notices
Compliance information, operating limits, and safety guidelines for the product.
