  • Page 1 00809-0100-4737 English Rev. EA Models 244EH and 244ER PC-Programmable Temperature Transmitters...
  • Page 2 For information on Rosemount nuclear-qualified products, contact your local Rosemount Sales Representative. Rosemount Models 244EH and 244ER Smart Temperature Transmitters may be protected by one or more U.S. Patents pending. Other foreign patents pending. Rosemount and the Rosemount logotype are registered trademarks of Rosemount Inc.

  • Page 3: Table Of Contents

    Table of Contents SECTION 1 Safety Messages ........1-1 Introduction Transmitter Overview .
  • Page 4 Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters APPENDIX A Transmitter Specification ......A-1 Reference Data Functional.

  • Page 5: Safety Messages

    • A compact size and two housing options allowing mounting flexibility for the control room or the field Rosemount Inc. has a full range of compatible connection heads, sensors, and thermowells to provide complete assemblies for process temperature measurements. Refer to Volume 1 of the Rosemount...

  • Page 6: Manual Overview

    Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters MANUAL OVERVIEW This manual is designed to assist in the installation, operation, and ® maintenance of Rosemount Model 244EH and 244ER PC Programmable Temperature Transmitters and the Model 244EC Configuration Interface. Section 2: Installation •...

  • Page 7: Considerations

    CONSIDERATIONS General Electrical temperature sensors such as RTDs and thermocouples produce low-level signals proportional to their sensed temperature. The Models 244EH and 244ER transmitters convert the low-level sensor signal to a standard 4–20 mA dc signal that is relatively insensitive to lead length and electrical noise.

  • Page 9: Safety Messages

    Section Installation Safety Messages ....... . page 2-1 Tools needed for Installation ..... . . page 2-2 Mounting .

  • Page 10: Tools Needed For Installation

    Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Figure 2-1. Transmitter Installation Flowchart Transmitter Begin Here Configured? Configure Field Transmitter Install Set Sensor Set Failure Type Mode Switch Set Number Mount of Wires Transmitter Wire Set 50/60 Hz Transmitter Filter...

  • Page 11: Mounting

    MOUNTING The Model 244EH installs in a connection head or universal head mounted directly on a sensor assembly, apart from a sensor assembly using a universal head, or to a DIN rail using an optional mounting clip. The Model 244ER mounts directly to a wall or to a DIN rail. The Models 244EH and 244ER transmitters will operate within specifications for ambient temperatures between –40 and 185 °F (–40 and 85 °C).

  • Page 12: Special Mounting Considerations

    Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Special Mounting Special mounting hardware is available for mounting a Model 244EH head mount transmitter to a DIN rail, or assembling Considerations a new Model 244EH to an existing threaded sensor connection head (former option code L1).

  • Page 13: Installation Procedures

    • an integral DIN style connection head • a standard extension • a threaded thermowell Refer to Volume 2 of the Rosemount Sensors Product Data Sheet (document number 00813-0101-2654) for complete sensor and mounting accessory information. To complete the assembly, follow the steps described below.
  • Page 14 • the universal connection head • a union and nipple extension assembly • a threaded thermowell Refer to Volume 1 of the Rosemount Sensors Product Data Sheet (document number 00813-0100-2654) for complete sensor and mounting accessory information. To complete the assembly, follow the steps as described below.
  • Page 15 • an integral DIN style connection head • a standard extension • a threaded thermowell Refer to Volume 2 of the Rosemount Sensors Product Data Sheet (document number 00813-0101-2654) for complete sensor and mounting accessory information. To complete the assembly, follow the procedure described below.
  • Page 16 • a threaded sensor connection head • a union and nipple extension assembly • a threaded thermowell Refer to Volume 1 of the Rosemount Sensors Product Data Sheet (document number 00813-0100-2654) for complete sensor and mounting accessory information. To complete the assembly, follow the procedure described below.

  • Page 17: Configuration Software

    Multichannel Installations Several transmitters can be connected to a single master power supply as shown in Figure 2-9. In this case, the system may be grounded only at the negative power supply terminal. In multichannel installations where several transmitters depend on one power supply and the loss of all transmitters would cause operational problems, consider a back-up battery or power supply that cannot be interrupted.
  • Page 18 Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Choose the procedure that matches the operating system you are using. Procedure for Windows 3.1 or Windows for Workgroups 3.11 1. If you do not have Win32s installed, install it now. Follow the instructions on the diskette label.

  • Page 19: Model 244Ec Configuration Interface

    Screen Conventions The Models 244EH and 244ER Configuration Software follows the Microsoft Windows screen conventions with the following exception: Configuration parameters change color to indicate fields where information has changed. Before placing a new transmitter into service, or before returning a transmitter to service after changing configuration information, verify that the values in the fields that have been changed reflect the correct configuration parameters for your application.

  • Page 20: Field Wiring

    Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters 5. Turn on the Model 244EC using the power switch on the top side of the housing. NOTE Verify that the Model 244EC “Low Battery” LED is not on before initiating communication with the transmitter. If the low battery LED is on, you will not be able to configure the transmitter.

  • Page 21: Sensor Connections

    Use the following steps to wire the transmitter: 1. Connect the positive lead from the power supply to the transmitter terminal marked “+” and the negative lead to the transmitter terminal marked “–” (see Figure 2-11 and Figure 2-13). 2. Tighten the terminal compression screws to ensure adequate contact.
  • Page 22 Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Sensor Lead Wire Resistance Effect RTD Input When using a 4-wire RTD, the effect of lead resistance is eliminated and has no impact on accuracy. However, a 3-wire sensor will not fully cancel lead resistance error because it cannot compensate for imbalances in resistance between the lead wires.
  • Page 23 Comp. and mV Loop * Rosemount Inc. provides 4-wire sensors for all single element RTDs. You can use these RTDs in 3-wire configurations by leaving the unneeded leads disconnected and insulated with electrical tape. ** The transmitters must be configured for a 3-wire RTD in order to recognize an RTD with a compensation loop.

  • Page 24: Failure Mode

    Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Figure 2-13. Transmitter Power, Sensor, and Configuration Terminals Model 244EH Model 244ER Sensor Sensor Terminal Terminals Configuration Terminals Failure Mode Switch Failure Mode Power/Configuration Switch Terminals Power Terminal FAILURE MODE The Models 244EH and 244ER features software driven alarm diagnostics and an independent circuit.

  • Page 25: Safety Messages

    To protect against high-energy transients, install Models 244E into a suitable connection head with the Rosemount Model 470 Transient Protector. The Model 470 prevents damage from transients induced by lightning, welding, heavy electrical equipment, or switching gears.

  • Page 26: Grounding

    Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Grounding The transmitter will operate with the current signal loop either floating or grounded. However, the extra noise in floating systems affects many types of readout devices. If the signal appears noisy or erratic, grounding the current signal loop at a single point may solve the problem.

  • Page 27: Configuring A Single Transmitter

    Configuring a Single Transmitter NOTE See “Configuration Software” on page 2-9 for instructions on how to install the configuration software. To configure a single Model 244EH or 244ER transmitter, perform the following procedure: 1. Disconnect power to the transmitter if the transmitter is installed in a measurement loop.

  • Page 28: Configuring Several Transmitters Identically

    Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters NOTE Each configuration parameter is explained in detail in the on-line help provided with the software. To access help, click the HELP button on the main configuration window (see Figure 3-1). 5. Click the SEND TO XMTR button to upload configuration information to the transmitter.

  • Page 29: Viewing The Process Variable

    Viewing the Process With version 2.0 and later of the Model 244EC Configuration Interface, users can view the measured temperature (PV) by selecting SERVICE Variable from the menu bar of the main configuration window (see Figure 3-2). In order to view a valid PV, a temperature sensor must be connected to the Model 244E transmitter, and the transmitter must be configured properly for that sensor type.

  • Page 30: Case Examples

    Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Case Examples Case 1: Open Sensor If the algorithm detects an open sensor, the transmitter immediately goes into alarm (high or low, depending on the position of the failure mode switch). Case 2: Temperature Change Greater than the Threshold Value(2% of Output Range) If the algorithm detects a process temperature change (∆T) greater...

  • Page 31: Intermittent Sensor Algorithm And Damping

    Step Changes Greater than Threshold Value Input Total of All Step Changes Output without Algorithm Output with Algorithm (Default) 0 500 1000 1500 2000 2500 3000 3500 4000 Time (in 500 ms increments) D) If an open sensor is validated at the end of the first update cycle (Time = 500 ms), the output will go directly to alarm level.

  • Page 32: Intermittent Sensor Detect (Advanced Feature)

    Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Figure 4-1 illustrates an example of intermittent sensor detect with damping enabled. If the temperature undergoes a step change greater than the threshold value, or from 100 degrees to 110 degrees, and the damping is set to 5.0 seconds, the transmitter calculates a new reading...

  • Page 33: Implementation

    Transmitter Behavior with Intermittent Sensor Detect ON When the Intermittent Sensor Detect feature is switched ON, the transmitter can eliminate the output pulse caused by intermittent open sensor conditions. Process temperature changes (∆T) within 2% of the output range will be tracked normally by the transmitter’s output. A ∆T greater than 2% of the output range will activate the intermittent sensor algorithm.

  • Page 35: Safety Information

    Section Maintenance and Troubleshooting Safety Information ....... page 4-1 Troubleshooting ....... . . page 4-1 SAFETY INFORMATION Procedures and instructions in this manual may require special precautions to ensure the safety of the personnel performing the...
  • Page 36 Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters The “Information Transmitter UNSUCCESSFUL” message appears because the transmitter did not accept the change made in the Intermittent Sensor Detect field. However, any other configuration changes sent at the same time as the Intermittent Sensor Direct change will be sent successfully.

  • Page 37: Transmitter Specification

    Appendix Appendix Reference Data Transmitter Specification ......page A-1 Ordering Information ......page A-6 Dimensional Drawings .

  • Page 38: Performance

    Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Failure Mode The values that the transmitter drives its output to in failure mode depend on whether it is factory configured to standard or NAMUR-compliant operation. The values for standard and NAMUR-compliant are as follows: TABLE A-1.
  • Page 39 Accuracy TABLE A-2. Model 244E Input Options and Accuracy. Sensor Sensor Input Recommended Options Reference Ranges Min. Span Accuracy (whichever is greater) 2-, 3-, 4-wire RTDs °C °F °C °F Pt 100 IEC 751, 1995 (α = 0.00385) –200 to 850 –328 to 1562 0.05% of span + 0.15 °C or 0.2 °C Pt 100...
  • Page 40 Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Ambient Temperature Effect Transmitters can be installed in locations where the ambient temperature is between –40 and 85 °C (–40 and 185 °F). At the factory, each transmitter is individually characterized over this ambient temperate range.

  • Page 41: Physical

    Physical Electrical Connections Power and Sensor Terminals Model 244EH Compression screws permanently Clips permanently fixed to fixed to terminal block terminal block Model 244ER: Compression screw permanently Clips permanently fixed to fixed to front panel front panel ® WAGO spring clamp terminals are optional (option code G5) Materials of Construction Construction Material for the Electronics Housing and Terminal Block ®...

  • Page 42: Ordering Information

    –14 NPT Entries) • — Integral Mount *****Order connection head through Volume 2 of the Rosemount Temperature Sensor and Accessories Product Data Sheet (document number 00810-0101-2654) sensor model number***** Configuration Options Analog Output Levels Compliant with NAMUR-Recommendations NE 43:June 1997 •...
  • Page 43 TABLE A-5. Model 244EC Configuration Interface Ordering Information • = Available — = Not available Model Product Description 244EH 244EC Model 244EC Configuration Interface Hardware and Software • Typical Model Number: 244EC TABLE A-6. Transmitter Accessories Part Description Part Number Aluminum Allow Universal Head, Standard Cover—M20 Entries 00644-4420-0002 Aluminum Allow Universal Head, Standard Cover—...

  • Page 44: For Temperature Assemblies

    Orders that include enclosure options J5 or J6 must be ordered from the Model 244EH ordering information table. When ordering a complete DIN style assembly, select the appropriate connection head from Volume 2 of the Rosemount Temperature Sensors and Accessories PDS (document number 00813-0101-2654). Standard Configuration...

  • Page 45: Dimensional Drawings

    DIMENSIONAL DRAWINGS Transmitter Model 244ER Model 244EH Shown with Standard Compression Screw Terminals 60 (2.4) 33 (1.3) Sensor Terminals ® WAGO Spring Clamp Sensor Terminals Communication 24 (1.0) Terminals Failure Mode Switch Power Terminals Power Terminals 33 (1.30) ® Shown with WAGO Spring Clamp Terminals 60 (2.4) 33 (1.3)

  • Page 47: Safety Messages

    Appendix Appendix Approvals Safety Messages ....... . page B-1 Hazardous Locations Installations ....page B-1 Locations Certifications .

  • Page 48: Locations Certifications

    Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters LOCATIONS Factory Mutual (FM) Approvals CERTIFICATIONS E5 Explosion-Proof for Class I, Division 1, Groups B, C, and D. Dust-Ignition Proof for Class II, Division 1, Groups E, F, and G. Dust-Ignition Proof for Class III, Division 1 hazardous locations when installed in accordance with Rosemount Drawing 00644-1049.
  • Page 49 = –40 to 65 °C). NOTE: Flameproof certification is only available as a complete assembly with Rosemount universal head – option codes J5 or J6. British Approvals Service for Electrical Equipment in Flammable Atmospheres (BASEEFA) Approvals ATEX II 1 G...

  • Page 50: Installation Drawings

    E7 Flameproof Approval (Model 244EH only) Ex d IIC T6 NOTE: Flameproof certification is only available as a complete assembly with Rosemount universal head – option codes J5 or J6. Gostandart Tested and approved by the Russian Metrological Institute GOSTANDART.
  • Page 51 Figure B-1. Canadian Standards Association (CSA) Intrinsic Safety Installation Drawing 00644-1064, Rev. AB...
  • Page 52 Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Figure B-2. Canadian Standards Association (CSA) Explosion-Proof Installation Drawing 00644-1059, Rev. AA...
  • Page 53 Figure B-3. Factory Mutual (FM) Intrinsic Safety Installation Drawing 00644-0009, Rev. AA...
  • Page 54 Rosemount Models 244EH and 244ER PC-Programmable Temperature Transmitters Figure B-4. Factory Mutual (FM) Explosion-Proof Installation Drawing 00644-1049, Rev. AB...
  • Page 55 Appendix Appendix Models 644 and 244E Temperature Transmitters Manual Supplement Old Transmitter ........page C-2 New Transmitter .

  • Page 56: Old Transmitter

    RTD and Comp. Loop * Rosemount Inc. provides 4-wire sensors for all single element RTDs. You can use these RTDs in 3-wire configurations by leaving the unneeded leads disconnected and insulated with electrical tape. ** The transmitters must be configured for a 3-wire RTD in order to recognize an RTD with a compensation loop.

  • Page 57: New Transmitter

    4-wire Comp. Loop * Rosemount Inc. provides 4-wire sensors for all single element RTDs. You can use these RTDs in 3-wire configurations by leaving the unneeded leads disconnected and insulated with electrical tape. ** The transmitters must be configured for a 3-wire RTD in order to recognize an RTD with a compensation loop.

  • Page 58: Specifications

    (1) For more information see approval certificate, Old: Model 644H: 95C2010X, Model 244E: 95C2019X; New: Model 644H: BAS00ATEX1033X, Model 244E: BAS00ATEX1034X (2) For more information see Rosemount drawing 00644-1040, Rev. B (old) and 00644-1064, Rev AB (new). (3) For more information see Rosemount drawing 00644-1056, Rev. B (old) and 00644-0009, Rev AA (new)
  • Page 59 Index Ordering ... A-6 Information Alarm Humidity ..A-5 Ordering Information see Failure mode 244EC, limits for ... . A-7 Accessories .
  • Page 60 Rosemount Model 3244MV MultiVariable Temperature Transmitter with Profibus-PA Wiring ... . . 2-13 diagrams ..2-15 Sensors diagram ....2-16...
