Summarization of Contents
3.0 SETTING UP THE SCALE
3.1 LIST OF ACCESSORIES
Lists items included in the scale package.
3.2 CONNECTING THE INDICATOR
Instructions for attaching the indicator to the base.
3.3 MOUNTING THE INDICATOR
Describes three ways to mount the indicator.
3.4 SETTING UP THE PILLAR VERSION SCALE
Details on setting up the pillar version of the scale.
3.5 INSTALLING BATTERIES
Instructions for installing batteries for power.
5.0 KEYPAD AND DISPLAY
5.1 KEYPAD
Explains the function of each key on the scale's keypad.
5.2 DISPLAY SYMBOLS
Describes the meaning of various symbols shown on the display.
6.0 OPERATIONS
6.1 SWITCHING ON THE SCALE
Steps to power on the scale and initial display sequence.
6.2 ZEROING THE SCALE
How to set the scale to zero or tare.
6.3 TARING THE SCALE
Detailed procedure for taring the scale with a container.
6.4 WEIGHING
Steps for performing a weighing operation.
6.5 SELECTING THE UNIT
How to choose the desired weighing units (kg, lb, oz).
6.6 PRINTING AND HOLDING FUNCTIONS
Explains the Print/Hold key functionality.
8.0 USER PARAMETERS
8.1 AUTO POWER OFF
Configures the automatic shutdown feature to save power.
8.2 SETTING OF BACKLIGHT
Adjusts the display backlight settings (on, off, auto).
8.3 ENABLING OF UNITS
Allows users to enable or disable specific weighing units.
8.4 COMMUNICATION ADDRESS
Sets the communication address (ID) for RS-232 output.
8.5 SELECTION OF BPS
Sets the Baud rate (BPS) for RS-232 communication.
8.6 SELECTION OF BIT RATE AND PARITY
Configures bit rate and parity for RS-232 data transmission.
8.7 SELECTION OF TRANSMISSION MODE
Selects how data is transmitted via RS-232 (e.g., continuous, on print).
8.8 SELECTION OF HOLD FUNCTION
Configures the hold function behavior (none, auto, manual).
8.9 SETTING OF HOLD TIME LIMIT
Sets the duration for which the display is held.
11.0 TECHNICAL PARAMETERS
11.1 FILTER
Adjusts display filtering for stability in different environments.
11.2 ZERO TRACKING
Configures the range of the zero tracking function.
11.3 STABILIZATION RANGE
Sets the range for the stability indicator.
11.4 STABILIZATION TRACKING
Adjusts the size of the stability indicator tracking range.
