Please read this booklet and keep for future reference for the safe
installation and operation of your:
forte or
Athena
aqualux AG
AG = CLEAN AIR
All installations must be in accordance with these instructions. Consult
with the building authority having jurisdiction to determine the need for
a permit prior to commencing the installation. Failure to follow these
instructions may also void your fire insurance and warranty.
This unit has been tested to Appendix E & B of the joint
Australia/New Zealand Standard 2918:2001
