INSTALLATION AND OPERATOR'S HANDBOOK
FOR THE FIRENZO INSERT KOMPACT FIRES
Please read this booklet for the safe installation and operation of your:
kompact
kompact
kompact
kompact
THE KOMPACT RU MODEL IS FOR
INSTALLATION ON PROPERTIES OF
2 HECTACRES OR MORE
The Appliance and Flue System must be installed in accordance
with AS/NZS2918:2001. Consult with the Building Authority having
jurisdiction to obtain a permit prior to commencing
the installation. Failure to follow these instructions may also void
ru
ru
ru
ru
your fire insurance and warranty.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Firenzo KOMPACT RU
Summary of Contents for Firenzo KOMPACT RU
- Page 1 Please read this booklet for the safe installation and operation of your: kompact kompact kompact kompact THE KOMPACT RU MODEL IS FOR INSTALLATION ON PROPERTIES OF 2 HECTACRES OR MORE The Appliance and Flue System must be installed in accordance with AS/NZS2918:2001. Consult with the Building Authority having jurisdiction to obtain a permit prior to commencing the installation.
- Page 2 Page 12/13 Diva Fascia Dimensions & Install Page 14/15 Athena Fascia Dimensions & Install Page 16/17 Deco Fascia Dimensions & Install Page 18/19 Forte Fascia Dimensions & Install Page 20/21 Plaza Fascia Dimensions & Install Edited 5/7/12 Kompact RU Installation...
- Page 3 THIS APPLIANCE SHOULD BE MAINTAINED AND OPERATED AT ALL TIMES IN ACCORDANCE WITH THESE INSTRUCTIONS. The Kompact RU is tested to N.Z. Standards AS/NZS 2918:2001. If this heater is incorrectly installed a house fire may result. For your safety follow the installation instructions carefully.
-
Page 4: Floor Protector Requirements
If the heater is to be installed onto a SOLID concrete floor protector (hearth) that has no heat sensitive materials in its construction it must meet the following MINIMIUM dimension as marked A & B from the above diagram: Kompact RU Installation... - Page 5 Dimensions A & B from above diagram must meet the following schedule: B HEIGHT (mm) A FROM FIRE BREAST Level 30mm 40mm 50mm Minimum width of floor protector must be 820mm and/or 410mm from centre of heater. Kompact RU Installation...
-
Page 6: Pre-Installation
The heater must be installed on a level non-combustible base. MANTEL CLEARANCE If the mantel shelf on your masonry fireplace is of a combustible material the minimum distance from the floor protector is as follows. This may be reduced if a Firenzo Kompact deflector is fitted. DEFLECTOR... -
Page 7: Assembly Instructions
A Unprotected B With Firenzo Deflector Kompact Diva Kompact Forte Kompact Athena 1100 Kompact Deco 1225 Kompact Plaza 1225 SIDE PILLAR CLEARANCE The minimum clearance from the side of the fascia to any heat sensitive material must be 5mm providing the material does NOT protrude more than 150mm. - Page 8 Where such action is considered the flue manufacturer should be consulted in the first instance. Refer also to notes on page 9 regarding height of flue system outlet. Kompact RU Installation...
- Page 9 1 metre above the roof penetration if more than 3 metres from the ridge. 3. No part of the building, or any adjacent building may be in or above a circular area of a horizontal radius of 3 metres from the flue exit. Kompact RU Installation...
- Page 10 6. TYPICAL INSTALLATION REQUIREMENTS WHITE KAOWOOL BLANKET PLACED ON TOP OF HEATER AIRPORTS INTO HEATER YELLOW I.S.B INSULATION DO NOT PACKED BETWEEN HEATER BLOCK CANOPY AND MASONRY ENCLOSURE MAX DEPTH OF 80mm 80mm MAX Kompact RU Installation...
- Page 11 UNDER NO CIRCUMSTANCES SHOULD THE AIR SUPPLY INTO THE AIRPORTS ON THE SIDE OF THE HEATER BE RESTRICTED BRICK / MASONRY FIRE BOX IN CANOPY ENCLOSURE I.S.B INSULATION (YELLOW) PACKED BETWEEN HEATER AND BRICK / MASONARY ENCLOSURE Kompact RU Installation...
- Page 12 7. FASCIA DIMENSONS, ASSEMBLY & INSTALLATION DIVA KOMPACT WITH FASCIA Kompact RU Installation...
- Page 13 Finally fit the door. Locate the hinges correctly by angling the door at approximately 45 degrees. 3. Add the extension (3) (provided in the fascia pack) to the air control rod Kompact RU Installation...
- Page 14 ATHENA KOMPACT WITH FASCIA Kompact RU Installation...
- Page 15 (Screws for granite ashlip (5) see illustration 2). These two screws protrude by 5mm to enable the ashlip to be lifted up and over the screw heads and then screw up tight. Kompact RU Installation...
- Page 16 DECO KOMPACT WITH FASCIA Kompact RU Installation...
- Page 17 (Screws for granite ashlip (4) see illustration These two screws protrude by 5mm to enable the ashlip to be lifted up and over the screw Kompact RU Installation heads and then screw up tight. Attach the bottom grill...
- Page 18 FORTE KOMPACT WITH FASCIA Kompact RU Installation...
- Page 19 Secure the top of the fascia with the three Fit the bottom grill. 15mm self tapping screws (4) (provided in the fascia pack) Finally fit the door. Locate the hinges correctly by angling the door at approximately 45 degrees. Kompact RU Installation...
- Page 20 PLAZA KOMPACT WITH FASCIA Kompact RU Installation...
- Page 21 (Screws for granite ashlip (4) see illustration These two screws protrude by 5mm to enable the ashlip to be lifted up and over the screw heads and then screw up tight. Kompact RU Installation Attach the bottom grill...
- Page 22 WOODFIRES HEWITSONS LIMITED Manufacturers of: Lady Kitchener Contessa Bronte Encore Viking Royale Zealandia Coaster Aqualux Athena Forte Plaza Deco 98 Niven Street PO Box 3231 Onekawa Napier Phone: 06 8438260 Fax: 06 8430505 Email: hothouse@firenzo.co.nz Website: www.firenzo.co.nz Kompact RU Installation...
