  • Page 1 MC-12 Software Version 1.1 Release & Errata Notes...
  • Page 2 781-280-0495 (Sales) 781-280-0499 (Service) This document should not be construed as a commitment on the part of Lexicon, Inc. The information it contains is subject to change without notice. Lexicon, Inc. Lexicon Part No. 070-14710 | Rev 1 | 04/02...

  • Page 3: Table Of Contents

    Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced Revised INPUT SETUP Menus ............4 5.1a .

  • Page 4: Revised Input Setup Menus

    Software Version 1.1 Release & Errata Notes Lexicon MAIN MENU SETUP INPUT SETUP DVD1 INPUT SETUP DVD1 5.1a MODE MODE ADJUST INPUTS DVD1 NAME DVD1 5.1a FILM AUDIO CONTROLS SPEAKERS DVD2 DIGITAL IN COAX-1 5.1a MUSIC SETUP REAR PANEL CONFIG...
  • Page 5 Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced MAIN MENU SETUP INPUT SETUP DVD1 INPUT SETUP Note: MODE ADJUST INPUTS DVD1 NAME DVD1 If the INPUT SELECT parameter on the AUDIO CONTROLS SPEAKERS DVD2 DIGITAL IN COAX-1 SETUP REAR PANEL CONFIG ANALOG IN NONE ZONE 2 ADV menu is set to AUTO in...

  • Page 6: Record In

    Software Version 1.1 Release & Errata Notes Lexicon MAIN MENU SETUP INPUT SETUP DVD1 INPUT SETUP Note: MODE ADJUST INPUTS DVD1 NAME DVD1 If the INPUT SELECT parameter on the AUDIO CONTROLS SPEAKERS DVD2 DIGITAL IN COAX-1 SETUP REAR PANEL CONFIG...

  • Page 7: New Listening Modes

    Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced Otherwise, the RECORD AUDIO OUTPUTS will mute. dts NEO:6 FILM Downmixes cannot be generated when the 5.1a BYPASS MODE ADJUST FILM listening mode is selected in the Main Zone. • Designed for playback of matrix-encoded PCM digital stereo •...

  • Page 8: Dts Neo:6 Music

    MODE ADJUST 5.1a FILM • Designed for playback of non-matrix-encoded PCM digital • A proprietary Lexicon listening mode. stereo music sources. • Designed for playback of 5.1 analog film sources. • Systems that include side and rear channels will derive six •...

  • Page 9: L7 Music

    5.1a MUSIC MODE ADJUST 5.1a SurEX • A proprietary Lexicon listening mode. • Designed for playback of 5.1 analog film sources. • Designed for playback of 5.1 analog music sources. • Converts the 5.1 analog input into digital audio for internal THX processing, allowing the 5.1 analog input to utilize...

  • Page 10: A 2-Channel

    Software Version 1.1 Release & Errata Notes Lexicon 5.1a STANDARD 5.1a 2-CHANNEL MODE ADJUST 5.1a STANDARD MODE ADJUST 5.1a 2-CHANNEL • Designed for playback of 5.1 analog sources. • Designed for recording 5.1 analog sources to stereo recording devices. •...

  • Page 11: Revised Listening Mode Status Menus

    Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced REVISED LISTENING MODE STATUS MENUS NEW LISTENING MODE PARAMETERS then This glossary contains additions and revisions to the listening mode SHIFT S T A T parameter descriptions that appear on page 5-20 of the MC-12 A second page has been added to the DOLBY D and dts(-ES) User Guide (Rev 1).

  • Page 12: A Standard

    Software Version 1.1 Release & Errata Notes Lexicon New Listening Mode Parameters MIX ROOM (SMALL, LARGE) (continued from page 11) The MIX ROOM parameter has been added to the DOLBY D STATUS menu. It indicates the size of the mixing room that was...

  • Page 13: Errata Notes

    Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced ERRATA NOTES 5. To accommodate THX level requirements, the MAIN AUDIO OUTPUTS labeled FRONT L/R are about 2dB lower than the The errata notes listed below reflect additions and modifications to ZONE 2 and RECORD AUDIO OUTPUTS when an analog input the MC-12 User Guide (Rev 1) based on Software Version 1.1.
  • Page 14 Software Version 1.1 Release & Errata Notes Lexicon Errata Notes 15. The level meters on the ANLG IN LVL menu might not indicate (continued from page 13) accurate input levels when a 5.1 analog input source is present 10. When the MAIN command bank is selected, pressing the 7/5...
  • Page 15 Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced 21. The 5.1 MONO, 5.1 MONO LOGIC, and 5.1 MONO SURR listening modes are designed for playback of Dolby Digital mono input sources. When a Dolby Digital 1.0 input source is present, the unit will automatically select the 5.1 MONO LOGIC listening mode.

  • Page 16: Revised Menu Tree

    Software Version 1.1 Release & Errata Notes Lexicon REVISED MENU TREE The menu tree that begins below replaces the menu tree that begins on page A-5 of the MC-12 User Guide (Rev 1). MAIN MENU MODE ADJUST AUDIO CONTROLS SETUP...
  • Page 17 Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced The menu pictured at the left prompts the selection of the desired input for configuration. Selecting an input Continued from page 16 accesses the corresponding INPUT SETUP menu pictured below. The parameters on the left side of this menu are INPUT SETUP identical regardless of which input is selected.
  • Page 18 Software Version 1.1 Release & Errata Notes Lexicon Menu Tree (continued) Selecting parameters on the INPUT SETUP menus pictured on page 17 accesses the corresponding menu pictured below. The menus pictured below are identical regardless of which input is selected (e.g. DVD1, DVD2, and so on).
  • Page 19 Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced SPEAKER SETUP CUSTOM SETUP THX SETUP SPEAKER DISTANCES LEVELS CALIBRATION 40Hz 60Hz 60Hz CUSTOM SETUP THX SPEAKER SETUP THX SETUP SPEAKER DISTANCES LEVELS CALIBRATION 60Hz FRONT L/R 40Hz !CAUTION! FRONT L/R THX 80Hz FRONT LEFT 0.0 ft...
  • Page 20 Software Version 1.1 Release & Errata Notes Lexicon TRIGGER SETUP TRIGGER (#) SETUP TRIGGER 1 REMOTE REMOTE ONLY TRIGGER 2 REMOTE DVD1 Menu Tree DVD2 (continued) Continued from page 16 LEVELS CALIBRATION INTERNAL NOISE TEST EXTERNAL NOISE TEST BASS PEAK LIMITERS...
  • Page 21 Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced MODE ADJUST FILM FILM PL II 2-CHANNEL 5.1 2-CHANNEL AUTO AZIMUTH RE-EQUALIZER SUB L/R LVL +0dB VOCAL ENHANCE +0.0dB CENTER MIX +0dB MUSIC VOCAL ENHANCE +0.0dB OUTPUT LEVELS CUSTOM 5 SPKR ENHANCE SURROUND MIX +0dB PL II...
  • Page 22 Software Version 1.1 Release & Errata Notes Lexicon Menu Tree (continued) MODE ADJUST FILM MUSIC 5.1a FILM 5.1a 2-CHANNEL VOCAL ENHANCE +0.0dB VOCAL ENHANCE +0.0dB CENTER MIX +0dB MUSIC 5 SPKR ENHANCE 5 SPKR ENHANCE SURROUND MIX +0dB PL II...
  • Page 23 Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced The STATUS menu for the active listening mode can be accessed with the remote control. Press the SHIFT button, then the STAT button to access the first page of the appropriate STATUS menu. Press the STAT button a second time to access the second page of the menu. Press the STAT button a third time to exit the menu.

  • Page 24: Revised Installation Worksheet (1)

    Software Version 1.1 Release & Errata Notes Lexicon REVISED INSTALLATION WORKSHEET (1) The installation that begins below replaces the installation worksheet that begins on page A-12 in the MC-12 User Guide (Rev 1). INPUT SETUP DVD1 DVD2 GAME TAPE TUNER...
  • Page 25 Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced SPEAKER SETUP REAR PANEL CONFIG TRIGGER SETUP (Circle One) CUSTOM SETUP THX SETUP 8 STEREO INPUTS 5 STEREO & 5.1 ANLG SETTING FRONT L/R THX 80Hz TRIGGER 1 CENTER THX 80Hz TRIGGER 2 DISPLAY SETUP SIDE L/R...

  • Page 26: Revised Installation Worksheet (2)

    Software Version 1.1 Release & Errata Notes Lexicon REVISED INSTALLATION WORKSHEET (2) The installation that begins below replaces the installation worksheet that begins on page A-12 in the MC-12 User Guide (Rev 1). INPUT SETUP DVD1 DVD2 GAME TAPE TUNER...
  • Page 27 Software Version 1.1 Release & Errata Notes MC-12/MC-12 Balanced SPEAKER SETUP REAR PANEL CONFIG TRIGGER SETUP (Circle One) CUSTOM SETUP THX SETUP 8 STEREO INPUTS 5 STEREO & 5.1 ANLG SETTING FRONT L/R THX 80Hz TRIGGER 1 CENTER THX 80Hz TRIGGER 2 DISPLAY SETUP SIDE L/R...

  • Page 28: Index

    Index SYMBOLS NUMBERS (continued) (continued) , 2, 13 5.1-Channel Input Sources, 12 CENTER MIX Parameter, 10 CAUTION , see DOLBY 5.1a 2-CHANNEL Listening Mode, 10, 22 (Menu Ill.) CENTER SPEAKER Menu, 19 (Ill.) , see dts NEO:6 5.1a BYPASS Listening Mode, 4, 5, 6, 7, 10, 11, 22 CNTR DLY SAMPLES Parameter, 10 , see dts (Menu Ill.)
  • Page 29 (continued) (continued) (continued) DOLBY D MODE Menu, 18 (Ill.) Encoding Input Source(s) DOLBY D STATUS Menu, 11, 12, 23 (Ill.) Input Signal, 11 Analog, 6, 7, 8, 13, 14 Dolby Digital Decoding, 5, 7 LOGIC7, 10 Digital, 5, 6, 7, 8, 13, 14 Dolby Digital EX Encoding, 12 Matrix, 7, 8, 11 Dolby Digital, 5, 6, 7, 11, 12, 13, 15...
  • Page 30 Index (continued) (continued) (continued) Listening Mode(s) Output(s)/OUTPUT(S) S/PDIF, RECORD AUDIO OUTPUT, 6, 13, 14 OUTPUT LEVELS Menu, 7, 8, 9, 10, 22 (Ill.) FRONT L/R, 13 SACD Player, 10, 13 Parameters, New, 11 to 12 MAIN AUDIO, 10, 12, 13 SAT INPUT SETUP Menu, 17 (Ill.) STATUS Menus, 11, 12, 14, 23 (Ill.) REAR L/R, 10, 12...
  • Page 31 Table of Contents, 3 TAPE INPUT SETUP Menu, 17 (Ill.) THX Button*, 14 THX SETUP Menu, 13, 19 (Ill.) THX SPEAKER SETUP Message, 19 (Ill.) TRIGGER (#) SETUP Menu, 20 (Ill.) TRIGGER OUTPUTS, 15 TRIGGER Parameters, 15 TRIGGER SETUP Menu, 15, 16 (Ill.), 20 (Ill.) TUNER INPUT SETUP Menu, 17 (Ill.) TV INPUT SETUP Menu, 17 (Ill.) USE LAST Setting, 15...
  • Page 32 Lexicon, Inc. 3 Oak Park Bedford, MA 01730-1441 USA 781-280-0300 781-280-0490 www.lexicon.com Customer Support 781-280-0300 781-280-0495 (Sales) 781-280-0499 (Service) Lexicon Part No. 070-14710 | Rev 1 | 04/02...
