HP P4522A - Traffic Management Server Sa8220 Getting Started Manual page 13

NOTE: Access is
controlled using Access
Control Lists. For more
information, see Chapter
5 in the User Guide.
Requirements
for DHCP
(Optional)
NOTE: DHCP is not
available during dual
NIC operations, or when
Serial Cable Failover is
enabled.
6. Login to the SA8220, using the factory defaults:
login:admin
password:admin
7. To permit all administration tasks to be performed without
restriction from all IP addresses and to enable IP forwarding,
type the following command:
HP SA8220#config sys security mode open
After the initial configuration, you do not need to access the Boot
Monitor again unless your network configuration changes.
While the SA8220 is booting, the front panel LEDs display a
characteristic start pattern. After the boot sequence concludes, the
Power LED is solid and the Status LED blinks. If you observe any
deviation from this behavior, see Appendix E in the User Guide. The
SA8220 normally requires approximately two minutes to boot.
When the procedure is complete, the monitor prompt appears (if
Autoboot is disabled).
DHCP provides a method by which devices using TCP/IP can obtain
configuration parameters automatically through the network at
restart. If you use DHCP, you must provide the DHCP server with
the following parameters for it to pass to the SA8220:
• IP address
• Netmask
• Default gateway
• Host Name (the SA8220's name)
• Domain (optional)
• Domain Name Server (optional)
Running Setup Using the Boot Monitor
11
