How to use the Simrad PI MaxiCharger
28
The Simrad PI MaxiCharger is a plain battery charger to be used
with large PI sensors.
Figure 12 Simrad PI MaxiCharger
Caution
The Simrad PI MaxiCharger must only be used to charge
the large PI sensors: PI Spread, PI Spread/Depth, PI
Remote/Depth, PI Height and PI SeineSounder. You
must NOT use this charger to recharge the "small" PI
sensors and the PS sensors, as the high charging current
may cause damage to the batteries in these sensors.
The Simrad PI MaxiCharger is provided with a small booklet
from the manufacturer (Mascot). Read this booklet before you
put the charger to work!
Daily operation
Observe the following procedure for daily operation.
1
Connect the charger to 230 Vac, and check that the charger
lamp is lit in yellow.
2
Ensure that mounting materials do not short circuit the
charging lugs.
• This may be ropes, wires, chains or other items that
obstruct or short circuit the electrical connections.
3
Attach the charging clamps to the sensor as follows:
• Red clamp: Positive (+) fastening lug
• Black clamp: Negative (–) fastening lug
• On every sensor the polarity of the fastening lugs are
engraved on the sensor body using + and – characters.
