Installation principles

316870/A
Observe the installation principles in the illustration.
Figure 4 Installation principles
C
A
(A) The PI Spread (or Spread/Depth) sensor is mounted in a
special adapter on the port door.
(B) The PI Remote/Depth sensor is mounted in a special adapter
on the starboard door.
(C) Communication link between the PI Spread (or Spread/Depth)
sensor and the PI hydrophone.
(D) Communication link between the PI Remote/Depth sensor
and the PI hydrophone.
(E) Communication link between the two sensors.
(F) Angle of attack.
F
D
E
Installation
B
(CD012200K)
9
