Simrad PI Remote/Depth
18
Figure 9 Graphical presentation on PI32
D1m
45.9
15
This example shows how the trawl door is located at 45.9 m
depth, and that the distance between the trawl doors is 25.6
meters. You can also see how these values have changed during
the last 20 minutes.
The purpose of the depth- and distance markers on the graphical
presentation is to keep an eye on how deep and how far apart the
trawl doors are situated. The depth sensor in the PI Remote/Depth
measures the distance from the sea surface and down. The PI
Spread sensor communicates with the PI Remote/Depth sensor to
measure the distance between the trawl doors.
1 Identify the sensor you wish to use, and make sure that the
sensor is connected to the PI32 with correct communication
channels and update rates.
2 Ensure that you have a graphical presentation active on your
PI unit.
3 Press the button to open the
ENT
• The
Marker line
marker lines on or off for sensors S1, S2 and S3.
4 Use the
Marker line
marker line(s) On.
5 Enter the requested values for the marker line
and
thickness Marker line delay
•
Marker line thickness
thickness (in pixels) of the marker line(s).
S2m
25.6
10 5
Graphic setup
parameter allows you to switch the
parameter to switch the requested
.
: Use this parameter to control the
C3
0
25
50
75
100
(CD012102D)
menu.
Marker line
316870/A
