Simrad PI Remote/Depth
20
Figure 10 Graphical presentation on PI44/PI54
167 49.5
D1[m] S2[m]
5
5
38kHz 1000W
17.5 15 12.5
This illustration shows that the trawl doors are presently situated
at 167 meters below the surface, and they are ascending with 5
meters per minute. The distance between the two trawl doors
is 49.5 meter, and this distance is increasing with 5 meters per
second.

Depth marker line

1 Identify the sensor you wish to use, and make sure that
the sensor is connected to the PI system with correct
communication channels and update rates.
2 Ensure that you have a graphical presentation active on your
PI system.
3 Press the button to open the
ADJ
4 Press the
GAIN+
dialogue.
5 Observe the list of sensors that appear. Only those sensors
that can provide a marker line are listed.
6 Set to On.
Auto
• This allows the PI unit to use the Trawl Calculator to
estimate the correct time delay. (This is not applicable
for purse seiners.)
• If you wish to calculate the delay yourself, set
Off. You must then enter the calculated value into the
column.
Delay
7 Enter requested value for
MEDIUM T 22.5 C o
10 7.5 5
Graphic setup
button repeatedly to reach the
.
Width
S 7.2kn DK 1050 m
2.5 min
0
50
100
150
200
250
(CD012106F)
menu.
Marker line
to
Auto
316870/A
