Assa Abloy EMTEK 4911CKUS10B Installation Manual

Installation Guide - Grip by Grip Entry Set - Double Cylinder Deadbolts
1. Active Door Prep
2-3/8"
1" Dia.
or
Edge Bores
2-3/4"
2-1/4"
5-1/2"
1/8"
Deep
2-1/4"
2-1/8" Dia.
Bores
1"
Installation Guide - Grip by Grip Entry Set - Dummy
1. Dummy Door Prep
2-3/8"
or
2-3/4"
2. Door Jamb Prep
1/8"
Deep
2. Outside Installation
Outside Dummy Plug
5-1/2"
2-1/8" Dia.
Bores
Plates and grips vary depending on style.
3. Outside Installation
Tailpiece Horizontal
3/16"
Deep
2-3/4"
1-1/8"
1-1/4"
Plates and grips vary depending on style.
4. Inside Installation
Tailpiece Vertical
3. Inside Installation
Inside Dummy Plug
IN4-DBLGRIPDB 06-04-2014
