GalvinCare
- NPT
PRODUCT CODES:
- 42037US
- 40707US (Kit)
SPECIFICATIONS
Anti-ligature designed hand held shower adaptor, allows for the easy removal of the hand shower after
use.
Durable chrome finish for easy cleaning and a homely look.
Utilises a quick connect fitting for safe, reliable shut off and easy attachment and release.
Can be adapted to existing hose and hand showers.
IMPORTANT: All GalvinCare
order.
TECHNICAL DATA
Inlet
Outlet
Headwork
Working Pressure Range (kPa)
Working Temperature Range (°C)
Finish
NOTE: Galvin Specialised continually strive to improve their products. Specifications may change without
notice.
TOOLS REQUIRED
Power drill
Spanner or adjustable crescent
Thread sealer
PRE-INSTALLATION
MOUNTING DETAILS – ROUGH IN & OVERALL DIMENSIONS
Ensure ½" NPT Male spud protrudes between 12 and 14mm from the finished wall face.
Drill anti-rotation hole as per rough in dimensions (maximum 3mm deep) – Anti-rotation grub screw.
supplied is for use on hard surfacess only (Eg.Tiles). If installation is on soft wall a longer grub screw is
recommended and this hole must be drilled deeper to suit.
Before installation all lines must be flushed.
Mental Health Hand Shower
®
Mental Health taps are tested and leave our premises in good working
½" NPT – Female
½" NPT – Male
N/A
Min
50
Max
500
Min
5
Max
80
Chrome
