Kuryakyn 1758 Installation

SKELETON HAND MIRROR SET
PARTS INCLUDED
1 Left Skeleton Hand Mirror—Black Head—Black Stem
1 Right Skeleton Hand Mirror—Black Head—Black Stem
1 Hardware Kit Containing:
2 5/16"-18 X 1-1/2" Socket Head Cap Screws
2 5/16"-18 X 2" Socket Head Cap Screws
2 5/16" Split Lock Washers
2 5/16" Internal Tooth Lock Washers
2 Double End Threaded Studs
1 Metric Hardware Kit Containing:
2 5/16" to M10-1.25 Adapter Studs
2 M10-1.25 Jam Nuts
1 5/16" to M10-1.25 Left Hand Thread Adapter Stud
1 5/16" - M10 Left Hand Thread Jam Nut
2 #10-32 X 3/16" Set Screws
1 Installation Instructions
Please read and understand entire instructions before starting installation.
THANK YOU FOR CHOOSING K
IN ORDER TO PROTECT YOU AND OTHERS FROM POSSIBLE INJURY AND/OR
PROPERTY DAMAGE OR LOSS, PLEASE PAY CLOSE ATTENTION TO ALL
INSTRUCTIONS, WARNINGS, CAUTIONS AND NOTICES REGARDING THE USE
AND CARE OF THIS PRODUCT.
IF INSTALLING THIS PRODUCT FOR ANOTHER PARTY,
PLEASE MAKE SURE THEY RECEIVE THIS COPY OF THE
INSTALLATION INSTRUCTIONS SO THEY ARE AWARE OF
THE IMPORTANT INFORMATION CONTAINED IN THEM.
TOOLS SUGGESTED
Set of Hex Wrenches, Set of Combination Wrenches, Red Thread Locker
STRICTLY OBSERVE THE FOLLOWING GUIDELINES IN ORDER TO USE THE
PRODUCT PROPERLY AND AVOID POTENTIALLY DANGEROUS ACCIDENTS.
STEP 1
Read and understand all steps in the instructions before starting the
installation. Park the motorcycle on a hard, level surface and turn off the
ignition.
STEP 2
Remove the stock mirrors from the hand controls; set them aside, they will not
be re-used.
Avoid damage to the motorcycle. Protect painted surfaces with a
soft cloth or blanket.
INSTALLATION ON HARLEY DAVIDSON MODELS
STEP 3
Determine which of the included socket head cap screws will provide maximum
thread engagement in the mirror stem without bottoming out.
1758-21MC-0512 -cont.-
ϋ
RYAKYN!
This indication alerts you to the fact that ignoring the
contents described herein may negatively affect product
performance and functionality.
This indication alerts you to the fact that ignoring
the contents described herein can result in potential
injury.
INSTALLATION
1758
CUSTOMER SERVICE
INSTALLATION QUESTIONS
techsupport@kuryakyn.com
LIMITED WARRANTY
Küryakyn warrants that any Küryakyn products
sold hereunder, shall be free of defects in
materials and workmanship for a period of one
(1) year from the date of purchase by the
consumer excepting the following provisions:
● Küryakyn shall have no obligation in the event
the customer is unable to provide a receipt
showing the date the customer purchased the
●The product must be properly installed,
maintained and operated under
●Küryakyn makes no warranty, expressed or
implied, with respect to any gold plated
●Küryakyn shall not be liable for any
consequential and incidental damages, including
labor and paint, resulting from failure of a
Küryakyn product, failure to deliver, delay in
delivery, delivery in nonconforming condition, or
for any breech of contract or duty between
Küryakyn and a customer.
●Küryakyn products are often intended for use in
specific applications. Küryakyn makes no
warranty if a Küryakyn product is used in
applications other than intended.
●Küryakyn electrical products are warranted for
one (1) year from the date of purchase by the
consumer. L.E.D.'S contained in components of
Küryakyn products will be warranted for defects
in materials and workmanship for 3 years from
the date of purchase where as all other
components shall be warranted for one(1) year.
This includes, but is not limited to; control
modules, wiring, chrome & other components.
●Küryakyn makes no warranty of any kind in
regard to other manufacturer¹s products
distributed by Küryakyn. Küryakyn will pass on
all warranties made by the manufacturer and
where possible, will expedite the claim on behalf
of the customer, but ultimately, responsibility for
disposition of the warranty claim lies
ABOUT OUR CATALOG
For purchasing Küryakyn® products, you
can receive a complete catalog free of charge.
Send the Proof-of-Purchase below with
your address to: Küryakyn, P.O. Box 339,
Please indicate either Accessories Catalog for
Harley-Davidson® or GL & Metric Cruisers.
Be sure to ask your local dealer about other
Küryakyn® products, the motorcycle parts and
accessories designed for riders by riders.
©2005 Küryakyn USA® All Rights reserved.
877.370.3604 (toll free)
or call 715.247.2983
product(s).
normal conditions.
products.
with the manufacturer.
Somerset, WI 54025.
