Kuryakyn 5951 Installation Instructions

INSTALLATION INSTRUCTIONS
THRESHER GRIPS FOR 7/8" BARS, SATIN BLACK
THANK YOU FOR CHOOSING KURYAKYN!
Protect yourself and others from possible injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices regarding the installation, use, and care of this product.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN POTENTIAL DEATH OR SERIOUS INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN MINOR OR MODERATE POTENTIAL INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN MAY NEGATIVELY AFFECT PRODUCT PERFORMANCE AND FUNCTIONALITY OR
DAMAGE THE PRODUCT ITSELF OR THE PRODUCT TO WHICH IT IS BEING ATTACHED.
ENSURE THAT THE FOLLOWING PARTS HAVE BEEN INCLUDED IN THE KIT:
1 Right-Side (Throttle) Grip — Larger Inner Diameter (1.035" ID)
1 Left-Side (Clutch) Grip — Smaller Inner Diameter (.875" ID)
2 End Caps (symmetrical)
2 Tubes of Adhesive
YOU WILL ALSO NEED:
Utility Knife with a Sharp Blade, Sandpaper, Electrical Tape, Non-Permanent Marker
PICTURES SHOWN ARE OF THE CHROME PARTS. INSTALLATION OF THE BLACK PARTS WILL BE THE SAME.
THESE INSTALLATION INSTRUCTIONS CONTAIN IMPORTANT INFORMATION. ENSURE THE END USER RECEIVES THIS COPY AND IS AWARE
OF ITS IMPORTANCE FOR FUTURE USE.
STEP 1
Read and understand all steps in the instructions before starting the
installation. Park the motorcycle on a hard, level surface and turn off
the ignition. Let motorcycle cool. Remove main fuse.
ACCIDENTAL VEHICLE START-UP COULD CAUSE DEATH OR SERIOUS
INJURY, REMOVE THE MAIN FUSE BEFORE PROCEEDING.
STEP 2
Remove the existing grips and bar end weights from the handlebars.
Using a razor blade or utility knife, cut the grip lengthwise from the
switch housing out towards the end of the grip. When cutting away the
existing grips, be certain not to cut through the throttle sleeve. Peel the
grip away from the handlebar or throttle sleeve. This may take some
effort, as the grips are glued on from the factory.
STEP 3
With sandpaper or emery cloth remove all grip and adhesive residue
from both the throttle sleeve (right side) and exposed handlebar (left
side). If your throttle sleeve has ribbed marks or other protrusions, it
will have to be sanded or ground smooth to allow the grip to slide into
place. The surface should be completely clean and slightly roughed
from sanding. With an ammonia based cleaner or similar degreasing
agent and a clean rag, wipe off the throttle sleeve and exposed
handlebar.
PAGE 1
305951
DPF-MRK-003 REV A 8/30/17
LEFT-SIDE
END
(SMALLER ID)
CAP
866 277 9598 | INFO@KURYAKYN.COM
454 COUNTY ROAD VV SOMERSET, WI 54025
5951
PIC 1
RIGHT-SIDE
END
(LARGER ID)
CAP
K U R YA K Y N . C O M
