DRIVING LIGHTS, SATIN BLACK
THANK YOU FOR CHOOSING KURYAKYN!
Protect yourself and others from possible injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices regarding the installation, use, and care of this product.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN POTENTIAL DEATH OR SERIOUS INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN MINOR OR MODERATE POTENTIAL INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN MAY NEGATIVELY AFFECT PRODUCT PERFORMANCE AND FUNCTIONALITY OR
DAMAGE THE PRODUCT ITSELF OR THE PRODUCT TO WHICH IT IS BEING ATTACHED.
ENSURE THAT THE FOLLOWING PARTS HAVE BEEN INCLUDED IN THE KIT:
2
Victory Driving Lights
1
Victory Inner Fairing Mount
1
Mounting Kit, containing
1 Right Hand Mount
1 Left Hand Mount
2 Pivot Mounts
YOU WILL ALSO NEED:
Hex key set (ball-end recommended), socket wrench set
THESE INSTALLATION INSTRUCTIONS CONTAIN IMPORTANT INFORMATION. ENSURE THE END USER RECEIVES THIS COPY AND IS AWARE
OF ITS IMPORTANCE FOR FUTURE USE.
THE END USER'S SAFETY DEPENDS UPON PROPER INSTALLATION OF THIS PRODUCT. IF A STEP IN THESE INSTRUCTIONS IS NOT
WITHIN YOUR CAPABILITIES OR YOU DO NOT HAVE THE CORRECT TOOLS, HAVE YOUR DEALER PERFORM THE PROCEDURE. IMPROPER
INSTALLATION OF THIS PRODUCT COULD RESULT IN DEATH OR SERIOUS INJURY.
ACCIDENTAL VEHICLE START-UP COULD CAUSE DEATH OR SERIOUS INJURY, REMOVE THE MAIN FUSE BEFORE PROCEEDING.
STEP 1
Read and understand all steps in the instructions before starting the
installation. Park the motorcycle on a hard, level surface and turn off
the ignition.
STEP 2
Remove the windshield using a hex key.
PAGE 1
305062
DPF-MRK-003 REV A 5/6/16
1
Hardware Kit, containing:
2 M6 x 1.0 x 60mm Socket Head Cap Screws
2 3/8-16 Locknuts
2 Pivot Domes
1
Wiring Kit, containing:
1 Keyed Power Lead
1 Negative Y-Adaptor
1 Ground Y-Adaptor
2 Dielectric Grease Packets
4 Insulted Female Bullet Receps 22-16
4 Male AMP Insulted Bullets 16-22 AWG
1 1/4" Insulated Female Spade Connector
1 1/4" Insulated Male Spade Connector
10 6" Cable Ties
K U R YA K Y N . C O M
866 277 9598 | INFO@KURYAKYN.COM
454 COUNTY ROAD VV SOMERSET, WI 54025
5062
Advertisement
Table of Contents
Related Manuals for Kuryakyn 5062
Summary of Contents for Kuryakyn 5062
- Page 1 DRIVING LIGHTS, SATIN BLACK 5062 THANK YOU FOR CHOOSING KURYAKYN! Protect yourself and others from possible injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices regarding the installation, use, and care of this product.
- Page 2 Note: Remove wind deflectors from outer fairing of motorcycle if it is equipped with them. K U R YA K Y N . C O M 866 277 9598 | INFO@KURYAKYN.COM PAGE 2 454 COUNTY ROAD VV SOMERSET, WI 54025...
- Page 3 “Power” on the lower right (brake side) corner. These wires go to the Heated grips switch on the dash. Disconnect the two. This will be used as Keyed Power for the Kuryakyn wire and relay kit. STEP 12 Locate the Negative Y-Adaptor. Connect the female connector, on the dark blue with pink tracer wire, to the single end of the Y-Adaptor.
- Page 4 STEP 15 Attach the Inner Fairing Mount using the hex head screws that were removed in Step 10. A KURYAKYN WIRING AND RELAY KIT IS REQUIRED FOR COMPLETION OF WIRING THE KEYED POWER LEAD, GROUND Y-ADAPTOR AND DRIVING LIGHTS. WIRING AND RELAY KITS 2328 OR 2202 ARE SOLD SEPARATELY.
- Page 5 M6 socket head cap screw, using a ball-end hex key. K U R YA K Y N . C O M 866 277 9598 | INFO@KURYAKYN.COM PAGE 5 454 COUNTY ROAD VV SOMERSET, WI 54025...
- Page 6 IT IS THE END USER’S RESPONSIBILITY TO ENSURE THAT ALL FASTENERS (INCLUDING PRE-ASSEMBLED) ARE TIGHTENED BEFORE OPERATION OF THE MOTORCYCLE. KURYAKYN WILL NOT PROVIDE WARRANTY COVERAGE ON PRODUCTS OR COMPONENTS LOST OR DAMAGED DUE TO IMPROPER INSTALLATION OR LACK OF MAINTENANCE.
- Page 7 BEFORE RIDING, ENSURE THAT THE INSTALLATION OF THIS PRODUCT DOES NOT INTERFERE WITH THE PROPER OPERATION OF THE MOTORCYCLE. K U R YA K Y N . C O M 866 277 9598 | INFO@KURYAKYN.COM PAGE 7 454 COUNTY ROAD VV SOMERSET, WI 54025 305062...
- Page 8 ©2015 KURYAKYN HOLDINGS, LLC ALL RIGHTS RESERVED KURYAKYN, KURYAKYN K logo and the marks appearing on this instruction sheet are registered and common law trademarks of Kuryakyn Holdings except noted third-party trademarks. A full listing of trademarks and trademark registrations owned by Kuryakyn Holdings can be found at www.kuryakyn.com/legal-notice.
