Kuryakyn 1796 Installation Instructions

TECH-CONNECT FAIRING MOUNT FOR VICTORY
Thank You For Choosing Küryakyn!
Protect yourself and others from potential injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices
regarding the installation, use, and care of this product.
ENSURE THAT THE FOLLOWING PARTS HAVE BEEN INCLUDED IN THE KIT:
1 Tech-Connect Device Holder
1 Fairing Mount Bracket
1 Hardware Kit, containing;
4
1
1
YOU WILL ALSO NEED:
Set of Metric hex wrenches, set of open end wrenches, socket set and ratchet, warm, soapy water and a clean rag

STEP 1

Read and understand all steps in the instructions before starting the installation. Park the motorcycle on a hard, level surface and turn
IGN OFF.

STEP 2

Remove the windshield; set it and the fasteners aside for now.
Cross Country Tour Models: Remove the two fasteners securing the clutch
-side windshield-mount to the bike; remove the mount; set it and the fasten-
ers aside for now.

STEP 3

Refer to PIC 1. Using warm, soapy water and a clean rag remove all dirt
and debris from the installation area; allow the area to dry completely.

STEP 4

Locate the included Device Holder, Bracket, Flat Washer, and Locknut.
Refer to PIC 2. Place the Bracket over the threaded stud end of the Device
Holder as shown. Secure the Bracket with the Locknut and Flat Washer.
1796-12MC-1115
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN
RESULT IN POTENTIAL DEATH OR SERIOUS INJURY.
This indication alerts you to the fact that ignoring the contents described herein may negatively affect product per-
formance and functionality or damage the product itself or the product to which it is being attached.
6" Cable Ties
¼"-20 Thin Nylon Locknut
¼" Flat Washer
Ensure proper adhesion of this product. Remove all grease,
oil, bugs, dirt, and other debris (including wax and polish)
from the installation area. Kuryakyn will not provide warranty
coverage on products or components lost or damaged due
to improper installation.
Do not attempt this installation in temperatures below 50°F
(10°C). Proper adhesive bonding ONLY occurs above 50°F
(10°C).
PIC 1
CLEAN + DRY
PIC 2
1796
CLUTCH-SIDE (LEFT)
Page 1
