Westin 56-13555 Installation Instructions Manual

AUTOMOTIVE PRODUCTS,
ITEM QUANTITY
1 2
2 2
3 1
4 1
5 2
6 6
7 6
8 6
9 6
10 6
11 12
12 12
13 24
14 24
15 2
16 2
17 2
18 6
ANTI-SEIZE LUBRICANT MUST BE USED ON ALL STAINLESS STEEL FASTENERS TO PREVENT THREAD DAMAGE AND GALLING
Driver Side Items Shown
For Items 2 and 5
Passenger Items Opposite
ITEM 1
Westin Automotive Products, Inc.
320 W. Covina Blvd
San Dimas, Ca. 91773
ECO #: W15-0174
P.N.: 75-1806-RevA
INSTALLATION INSTRUCTIONS
APPLICATION:
2009-2015 Dodge Ram - Quad Cab / Crew Cab - 1500
2009-2015 Dodge Ram - Quad Cab / Crew Cab - 2500 / 3500
(Excl. Cab Chassis w/Def Tank)
PART NUMBER:
56-13555, 56-13565
CENTER MOUNT BRACKET, DRIVER AND PASSENGER
DRIVER FRONT MOUNT BRACKET
PASSENGER FRONT MOUNT BRACKET
REAR MOUNT BRACKET, DRIVER AND PASSENGER
M8 HEX RIV-CERT (YELLOW ZINC)
M10 SPLIT LOCK WASHER (YELLOW ZINC)
M10 FLAT WASHER (YELLOW ZINC)
LONG M8 HEX HEAD CAP SCREW (YELLOW ZINC)
SHORT M8 HEX HEAD CAP SCREW (YELLOW ZINC)
M8 SPLIT LOCK WASHER (YELLOW ZINC)
M8 FLAT WASHER (YELLOW ZINC)
M6 BUTTON HEAD CAP SCREW (BLACK ZINC)
M6 SERRATED FLANGE NUT (BLACK ZINC)
ITEM 2
HDX Drop Step
CONTENT
DESCRIPTION
STEP BAR ASSEMBLY
M10 BOLT / M8 NUT PLATE
M10 HEX NUT (YELLOW ZINC)
M6 FLAT WASHER (BLACK ZINC)
M10 PLASTIC RETAINER SQUARE
ITEM 3
1
ITEM 4
Thank You for choosing Westin products
For Additional installation assistance please call
Customer service (800) 793-7846
www.westinautomotive.com
TOOLS NEEDED
RATCHET
TORQUE WRENCH
10MM SOCKET
13MM SOCKET
13MM WRENCH
SOCKET EXT.
ALLEN WRENCH
ITEM 5
DATE: 04/18/16
