French Country Desk With Drawer
HARDWARE LIST
CODE
NAME
ALLEN SCREW
A
(Φ1/4"*51mm)
LOCK WASHER
B
( Φ1/4")
FLAT WASHER
C
(Φ1/4"*16mm)
ALLEN WRENCH
D
(M4x21x57mm)
E
HANDLE
Please do not return to the store
. Broken or Missing Parts?
. Need help with Assembly?
If you have any questions just call 1-800-468-6447 or email us at
parts@convenience-concepts.com
ITEM NO. 6042195
FIGURE
Q'TY
8PCS
8PCS
8PCS
1PC
1PC
6042196
6042199
PARTS LIST
CODE
NAME
DESKTOP
1
LEG
2
COLOR STICK
3
FIGURE
Q'TY
1PC
4PCS
1PC
CT0086S
Advertisement
Related Manuals for convenience concepts 6042195
Summary of Contents for convenience concepts 6042195
- Page 1 French Country Desk With Drawer ITEM NO. 6042195 6042196 6042199 HARDWARE LIST PARTS LIST CODE NAME FIGURE Q'TY CODE NAME FIGURE Q'TY ALLEN SCREW 8PCS DESKTOP (Φ1/4"*51mm) LOCK WASHER 8PCS 4PCS ( Φ1/4") FLAT WASHER 8PCS COLOR STICK (Φ1/4"*16mm) ALLEN WRENCH...
- Page 2 1. Place desktop upside down on carpet or other soft surface. 2. Attach all four legs to desktop using allen screws and the allen wrench (provided). STEP 1 2. Attach all four legs to the desktop as shown in the circle diagram above. Place the lock washer (B) onto the allen screw first.Followed by the flat washer (C) and screw then into each leg.
