Forging Mount HY9414-B Instruction Manual

www.forgingmount.com
Instruction Manual
FULL MOTION
TV WALL MOUNT
Model :. HY9414-B
VESA:400X400mm (Max)
Tape Electric 1/2 in (13 mm)
Measure Pencil Screwdriver Drill Socket Wrench
7/32in.
(5.5mm)
Wood
Stud Finder Awl Drill Bit Hammer
Step 1-1 Select TV Screw Diameter Step 1-2 Select TV Screw Length
Hand thread screws into the threaded inserts
If your TV has a flat back, AND you want your TV closer
on the back of your TV to determine which
to the wall, use the shorter screws(A).
screw diameter ( M4, M6, or M8 ) to use.
Use the spacers and longer screws(B) to accommodate:
M4 M6 M8
Does your TV (including accessories)
weigth more than 99 lbs. ( 45 kg )?
No — Perfect!
V2.1
Yes— This mount is NOT compatible.
capacity can result in serious personal
injury or damage to equipment! It is the
installers's responsibility to make sure the
weight of the TV (with accessories) does
not exceed 99 lbs(45kg).
Arm Assembly/ Wall Plate
WARNING: This product
contains small items that could
be a choking hazard if swallowed.
Before starting assembly, verify
all parts are included and
undamaged. If any parts are
missing or damaged, do not return
the damaged item to your dealer;
Wallplate Template
contact with Customer Service.
Never use damaged parts!
3/8in.
(10mm)
NOTE: Not all parts and hardware
Concrete
Drill Bit
included will be used.
· Round/irregular back TVs
· TVs with inset mounting holes
· Extra space needed for cables
FLAT BACK ROUND BACK INSET HOLES CABLES
What is your wall made of ?
99lbs
(45kg)
Perfect!
Solid concrete or
Exceeding the weight
concrete block?
TV Bracket
02
x2
TV Plate
03
x1
01
x1
Level Velcro Tie
04 05 06
x1 x1 x5
STEP1-3 Attach the TV plate to the arm assembly
Standard configurations
are shown. For special
TV plate connect with arm
applications, or if you
are uncertain about your
hardware selection,
you can contact at:
forgingmount888@163.com
CAUTION:
Verify
adequate thread engagement
with the screw/washer/spacer
combination and TV bracket.
-Too short will not hold the TV.
-Too long will damage the TV.
Too Short
Correct
Too Long
N
M
Please read through these instructions completely to be sure you're comfortable with
this install process. Also check your TV owner's manual to see if there are any special
Dry wall with
requirements for mounting your TV.
woodstuds ?
If you do not understand these instructions or have doubts about the safety of the installation,
assembly or use of this product, please contact US via: forgingmount888@163.com
CAUTION:
Avoid potential personal injuries and property damage!
This product is designed for use in wood stud/concrete walls DO NOT install into drywall.
The wall must be capable of supportingfive times the weight of the TV and mount combined.
Do not use this product for any purpose not explicitly specified by manufacturer.
Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
Lag Bolt
Lag Bolt
TV Screws
Washers
5/16x2.75"
M4X12mm M4X30mm
A B
x4 x4
D E
x4 x4
Wall Anchor
C
x4
M6X15mm M6X35mm
F G
WARNING
: x4 x4
Installation must use the
screws and accessories
provided by our company,
otherwise we are not
M8X15mm M8X30mm M8X50mm
responsible for any
H I
x4 x4
problems.
TV Washers Securement Screws Wrench
Ø5 Ø8 M5X12mm Ø5
J-1 J-2 M N
O
x4 x4 x2 x2
TV Spacers
L2.5MM L10MM L22MM
K L T
X
x8 x4 x4
x4
www.forgingmount.com
MAX=400mm , MIN=100mm 120mm
840mm
x1
