www.forgingmount.com

Full Motion TV Wall Mount

Instruction Manual

V2.0

VESA: 400X400mm(Max)

Model: HY9001-B

Thank you for choosing our product! We strive to provide the best quality

and services for our customers. Would you kindly share your experience

free contact us.

Email: forgingmount888@163.com

We're ready to help!

Need help?

Do you have a question about the HY9001-B and is the answer not in the manual?

Questions and answers

Summary of Contents for Forging Mount HY9001-B

Page 1 Full Motion TV Wall Mount Instruction Manual V2.0 VESA: 400X400mm(Max) Model: HY9001-B Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience free contact us. Email: forgingmount888@163.com...
Page 2 40kg 40kg forgingmount888@163.com forgingmount888@163.com Stud Tape Pencil Electric 7/32 in. 3/8 in. 1/2 in. Screwdriver Hammer (13 mm) Finder Measure Drill (5.5 mm) (10 mm) Wood Drill Concrete Drill Socket Wrench...
Page 3 Arm Assembly / Wall Plate TV Plate Extensions TV Mount Plate Level Velcro Tie Allen Key Wrench WARNING: This product contains small items that could be a choking hazard if swallowed.Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;...
Page 4 STEP 1-1 Select TV Screw Diameter and Length Select TV Screws screws or screws/spacers combination. We recommend thread engagement by at least 5 turns. -Too short will not hold the TV. -Too long will damage the TV. Too Short Too Long Correct Correct Assemble the TV Plate according to the measured value of TV hole...
Page 5 STEP 1-4 Attach the TV Plate / Extensions to TV back Position your TV Plate/Extensions over your TV hole pattern- making sure they are centered and level over the TV hole pattern.Secure the TV Plate/Extensions using your (a) for Flat Back (b) for Round Back/Extra space CAUTION: Ensure TV Plate/Extensions is securely fastened before moving on to the next step.
Page 6 MUST BE on to the next step. 2A-1 Position arm assembly/wall plate [01] at your desired height. Level the wall plate and mark the hole locations. 3 in.(75mm) 2A-2 ø3/8 in.(10mm) Drill 3 pilot holes using a 3/8 in. (10mm) diameter drill bit. Make sure the depth is not less than 3 in.(75mm) .NEVER drill into the mortar between blocks.
Page 7 2A-4 plate [01] using lag bolts [A] and washer [B] . Tighten the lag bolts [A] only until the wall plate. DO NOT over-tighten the lag bolts. Drywall covering the wall must not exceed 5/8 in. (16mm) Ensure the wall plate is securely fastened to the wall before continuing on to the next step.
Page 8 2B-2 Position arm assembly/wall plate [01] at your desired height. Level the wall plate and mark the hole locations. 3 in.(75mm) 2B-3 ø7/32 in.(5.5 mm) Drill 3 pilot holes using a 7/32 in. (5.5mm) diameter drill bit. Make sure the depth is NOT less than 3 in.(75mm).
Page 9 STEP 3 Attach TV to the arm assembly the hang tab [S] then resting the TV into place. STEP 4 Tighting locking bolts CAUTION: Avoid potential personal injury or property damage! Must be installed to secure the TV to the arm assembly!
Page 10 Adjustment Loosen the Bolt Tighten the Bolt...
Page 11 40kg forgingmount888@163.com forgingmount888@163.com Chercheur Ruban Crayon Perceuse 7/32 po. 3/8 po. 1/2 po. Tournevis Marteau à mesurer électrique (5.5 mm) (10 mm) (13 mm) Perceuse Forage Clé à douille à bois de béton...
Page 12 Assemblage de bras / Extensions pour TV Board Plaque de montage TV plaque murale Horizontal Attaches Velcro Clé Allen Clé à douille ALERTE : Ce produit contient de petits objets qui pourraient présenter un risque d'étouffement en cas d'ingestion. Avant de commencer l'assemblage, vérifiez que toutes les pièces sont incluses et en bon état. Si des pièces manquent ou sont endommagées, ne renvoyez pas l'article endommagé...
Page 13 ÉTAPE 1-1 Sélectionner le diamètre et la longueur de la vis TV Sélectionner la vis TV pour votre TV. - trop court pour la TV. - trop de temps peut endommager la TV. C'est C'est vrai. Trop court. C'est vrai. trop long.
Page 14 (a) Pour dos plat (b) Pour dos rond / Espace supplémentaire !ATTENTION: Pour dos plat Pour dos rond / Espace supplémentaire...
Page 15 !ATTENTION: Évitez les blessures corporelles ou les dommages matériels potentiels! Tous les boulons de traction [A] . fermement serrés pour éviter tout mouvement accidentel de la Plaque murale [01]. !ATTENTION: 2A-1 mural [01] à la hauteur souhaitée. Nivelez le panneau mural et 3 po.(75mm) 2A-2 ø3/8 po.(10mm)
Page 16 2A-4 boulons à tête carrée [A] et rondelles [B] . Serrez uniquement les boulons à tête reposent fermement sur la Plaque murale. Ne pas trop serrer les boulons à tête carrée. * Lla cloison s è che couvran le mur ne doit pas d é passer 5/8 in.(16mm) Évitez les blessures corporelles ou les dommages matériels potentiels! Tous les boulons de traction [A] doit être solidement serré...
Page 17 2B-2 mural [01] à la hauteur souhaitée. Nivelez le panneau mural et 3 po.(75mm) 2B-3 ø7/32 po.(5.5 mm) de diamètre. Assurez - vous que la profondeur 2B-4 boulons à tête carrée [A] et rondelles [B] . Serrez uniquement les boulons à tête reposent fermement sur la Plaque murale.
Page 18 ÉTAPE 3 Connecter le TV au bras TV en place. ÉTAPE 4 Visser le verrou ATTENTION! Évitez les blessures corporelles ou les dommages matériels potentiels ! doit être installé pour fixer le téléviseur à l'assemblage du bras !
Page 19 Adjustment à nouveau. Desserrer Serrer et serrer à nouveau. Desserrer les boulons Serrer les boulons...
Page 20 Thank you again for choosing this forgingmount product!
