For Full Motion TV Wall Mounts
Model: HY9390-B
If your package missing the accessories, please contact us at any time:
Email: forgingmount888@163.com
we will reply you immediately to solve your issue.
Thank you for choosing one of our Full Motion TV Wall Mounts. We hope
this FAQ guide will help answer any questions you have when installing the
TV mount.
Advertisement
Related Manuals for Forging Mount HY9390-B
Summary of Contents for Forging Mount HY9390-B
- Page 1 For Full Motion TV Wall Mounts Model: HY9390-B If your package missing the accessories, please contact us at any time: Email: forgingmount888@163.com we will reply you immediately to solve your issue. Thank you for choosing one of our Full Motion TV Wall Mounts. We hope this FAQ guide will help answer any questions you have when installing the TV mount.
- Page 2 Question 1 Can the TV wall mount be installed on the sheetrock/drywall alone? Answer: No, the TV wall mount can not be installed on the sheetrock/drywall alone. This product is designed for use on the wood stud, solid concrete and brick walls. CAUTION DO NOT install the TV wall...
- Page 3 Question 3 With the cables on the TV back. Answer: First plug in the cable, then add the spacers to create extra space between the TV and the TV brackets. Bolt Washer Bracket Spacers TV Back Cable Question 4 How to find the right height when mounting the TV? Answer: Scan the QR code to watch the mounting video.
- Page 4 Question 6 Answer: Before attaching the TV to the mount, please try to pull down the TV wall mount - 3 -...
- Page 5 Question 7 PLEASE NOTE: This answer is only suitable for the TV that has a bolt Answer: Step 1 Remove the TV from the TV wall mount. Step 2 Remove the TV brackets on the TV. (For lifting up the TV, follow the Step 3 Re-attach the TV on the TV Wall Mount.
- Page 6 Question 8 The TV is unlevel. After installation your TV is Answer: not level , please adjust the bolt [M] to level the Level angle in place. Drill hole should be horizontal, you can adjust the level by hand. Caution: When making this adjust, please know that bolt(M) also hold your TV to the mount.
- Page 7 Check if the bolt holes are at the same level. Move both TV brackets Check if the wall plate is level with bubble upward to reduce the gap between the holes level. If wall plate not level, adjust it to level. and bolts, then tighten the bolts.
- Page 8 Question 10 Can not adjust the tilting angle of the TV. Question 10 Check if the nut are too loose to hold the tilting angle. Please tighten the nut to hold the angle in place. Use the tool to loosen the nut on the front end of the arm. Then tilt the TV to your desired angle.
