Page 1
Full Motion TV Wall Mount Instruction Manual V2.0 VESA: 400X400mm(Max) Model: HY9001-B Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience free contact us. Email: forgingmount888@163.com...
Page 2
40kg 40kg forgingmount888@163.com forgingmount888@163.com Stud Tape Pencil Electric 7/32 in. 3/8 in. 1/2 in. Screwdriver Hammer (13 mm) Finder Measure Drill (5.5 mm) (10 mm) Wood Drill Concrete Drill Socket Wrench...
Page 3
Arm Assembly / Wall Plate TV Plate Extensions TV Mount Plate Level Velcro Tie Allen Key Wrench WARNING: This product contains small items that could be a choking hazard if swallowed.Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;...
Page 4
STEP 1-1 Select TV Screw Diameter and Length Select TV Screws screws or screws/spacers combination. We recommend thread engagement by at least 5 turns. -Too short will not hold the TV. -Too long will damage the TV. Too Short Too Long Correct Correct Assemble the TV Plate according to the measured value of TV hole...
Page 5
STEP 1-4 Attach the TV Plate / Extensions to TV back Position your TV Plate/Extensions over your TV hole pattern- making sure they are centered and level over the TV hole pattern.Secure the TV Plate/Extensions using your (a) for Flat Back (b) for Round Back/Extra space CAUTION: Ensure TV Plate/Extensions is securely fastened before moving on to the next step.
Page 6
MUST BE on to the next step. 2A-1 Position arm assembly/wall plate [01] at your desired height. Level the wall plate and mark the hole locations. 3 in.(75mm) 2A-2 ø3/8 in.(10mm) Drill 3 pilot holes using a 3/8 in. (10mm) diameter drill bit. Make sure the depth is not less than 3 in.(75mm) .NEVER drill into the mortar between blocks.
Page 7
2A-4 plate [01] using lag bolts [A] and washer [B] . Tighten the lag bolts [A] only until the wall plate. DO NOT over-tighten the lag bolts. Drywall covering the wall must not exceed 5/8 in. (16mm) Ensure the wall plate is securely fastened to the wall before continuing on to the next step.
Page 8
2B-2 Position arm assembly/wall plate [01] at your desired height. Level the wall plate and mark the hole locations. 3 in.(75mm) 2B-3 ø7/32 in.(5.5 mm) Drill 3 pilot holes using a 7/32 in. (5.5mm) diameter drill bit. Make sure the depth is NOT less than 3 in.(75mm).
Page 9
STEP 3 Attach TV to the arm assembly the hang tab [S] then resting the TV into place. STEP 4 Tighting locking bolts CAUTION: Avoid potential personal injury or property damage! Must be installed to secure the TV to the arm assembly!
Page 10
Adjustment Loosen the Bolt Tighten the Bolt...
Page 11
40kg forgingmount888@163.com forgingmount888@163.com Rivelatore Matita Trapano 7/32 pollici. 3/8 pollici. 1/2 pollici. Cacciavite Martello Metro a (13 mm) nastro Elettrico (5.5 mm) (10 mm) Trapano Trapano Chiave per legno per cemento a presa...
Page 12
Assemblaggio del braccio / Estensioni della piastra TV Piastra di montaggio TV piastra da parete Fascetta in Velcro Livellatore Chiave esagonale interna Chiave a presa ATTENZIONE: questo prodotto contiene piccoli oggetti che potrebbero rappresentare un rischio di soffocamento se ingeriti. Prima di iniziare il montaggio, verificare che tutte le parti siano incluse e non danneggiate.
Page 13
Seleziona viti TV Solo una dimensione di viti si adatta alla TV. combinati. -Troppo corto non reggerà la TV. -Troppo lungo danneggerà la TV. Troppo Troppo corta Corretto Corretto lungo Assemblare la scheda TV secondo il valore misurato del modello del Larghezza Altezza 75 mm= 7.5cm...
Page 14
Posizionare la piastra TV/Estensioni sul modello del foro TV-assicurandosi che siano centrati e livellati sul modello del foro TV.Fissare la piastra TV/Estensioni utilizzando (a) Per la schiena piatta (b) Per lo schienale rotondo/Spazio extra ATTENZIONE: prima di passare al passaggio successivo. Per la schiena piatta Per lo schienale rotondo/Spazio extra...
Page 15
Evitare potenziali lesioni personali o danni materiali! Tutti i bulloni [A] DEVE ESSERE saldamente serrati per evitare movimenti indesiderati della piastra di parete [01]. prima di procedere al passaggio successivo. 2A-1 Posizionare il gruppo braccio/ desiderata. Livellare la piastra di parete e contrassegnare le posizioni del foro.
Page 16
2A-4 braccio/piastra della parete [01] utilizzando bulloni di ritardo [A] e rondella [B] . Stringere i bulloni non sono tirati saldamente contro la piastra della parete. NON stringere eccessivamente i bulloni di ritardo. Evitare potenziali lesioni personali o danni materiali! Tutti i bulloni [A] DEVE ESSERE saldamente serrato per evitare movimenti indesiderati della piastra di parete [01] al passaggio successivo.
Page 17
2B-2 Posizionare il gruppo braccio/ desiderata. Livellare la piastra di parete e contrassegnare le posizioni del foro. 3 pollici (75mm) 2B-3 ø7/32 pollici (5.5 mm) Perforare 3 fori pilota utilizzando diametro.Assicurarsi che la profondità non sia inferiore a 3 pollici (75mm). 2B-4 braccio/piastra della parete [01] utilizzando bulloni di ritardo [A]...
Page 18
Appendere la TV al gruppo braccio [01] agganciando appoggiando la TV in posizione. Stringa il bullone di bloccaggio Attenzione! Evitare potenziali lesioni personali o danni materiali! deve essere installato per fissare la TV al gruppo braccio!
Page 19
Adjustment Regolazione Allentare Stringa stringere di nuovo. Sciogli il bullone Stringi il bullone...
Page 20
Thank you again for choosing this forgingmount product!
