SilverStone Flex ATX Series Manual

350 watt flex atx power supply with fixed cables and 80 plus gold with 6pin pcie connector
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Flex ATX SERIES
SST-FX350-G
The reference Flex ATX power supply
Support standard Flex ATX form factor
High efficiency with 80 PLUS Gold certification
350W continuous power output at 40℃ operating temperature rated for 24/7 operation
Class-leading single +12V rail
Support PCIe 6pin connector
Active PFC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flex ATX Series and is the answer not in the manual?

Questions and answers

Related Manuals for SilverStone Flex ATX Series

Summary of Contents for SilverStone Flex ATX Series

  • Page 1 Flex ATX SERIES SST-FX350-G The reference Flex ATX power supply Support standard Flex ATX form factor High efficiency with 80 PLUS Gold certification 350W continuous power output at 40℃ operating temperature rated for 24/7 operation Class-leading single +12V rail Support PCIe 6pin connector...

  • Page 2: Specification

    SPECIFICATION Flex ATX Form Factor SST-FX350-G 350W Switching Power Supply With Active PFC 80Plus Gold 1.0 INPUT: 1.1 VOLTAGE MINIMUM NOMINAL MAXIMUM UNITS 100~240 Vrms 1.2 FREQUENCY 47Hz ~ 63Hz 1.3 CURRENT 115Vac / 5A max. 230Vac / 2.5A max. 1.4 INRUSH CURRENT No damage...

  • Page 3: Power Efficiency

    1.5 POWER EFFICIENCY MEET 80 Plus Bronze at 115/230Vac input. LOAD 3.3V +12V -12V +5VSB SPEC 1.53A 1.86A 4.48A 0.05A 0.38A 3.83A 4.66A 11.19A 0.12A 0.96A 100% 7.67A 9.31A 22.38A 0.23A 1.92A In order to meet Eup* requirements the following quidance must be met for the 5Vsb efficiency at 230V AC.
  • Page 4  ＊ The continuous total output power is 350W max. • The combined power of +5V and +3.3V is 90W max.  ＊ Add 0.1uF and 10uF capacitors across output terminal during ripple & noise test. ＊  LOAD REGULATION TEST TABLE: +3.3V +12V -12V...

  • Page 5: Turn-On Delay Time

    2.6 TURN-ON DELAY TIME 2000 msec max.At nominal line full load. 2.7 TRANSIENT OVERSHOOT +/-10% max with 30% load change(+12V 40% load chang) on all outputs are 100% of the rated. Load slew rated 1A/uS and capacitive load as below : +3.3V +12V -12V...
  • Page 6 3.0 PROTECTION When OPP, OVP,OTP or short protection is triggered, the main outputs will be latched off. The main outputs can be reset by cycling the DC remote on/off or AC power. +5Vsb output is auto recovery when fault condition removed. 3.1 OVER POWER PROTECTION Foldback at 115%~150% over peak load 3.2 OVER VOLTAGE PROTECTION...

  • Page 7: Conducted Emi

    6.0 CE REQUIREMENTS 6.1 CONDUCTED EMI 1. MEET FCC： Class B 2. MEET CISPR 22： Class B 3. MEET BSMI： Class B 6.2 SAFETY STANDARDS 1. MEET CUL (UL 60950) 2. MEET TUV EN60950 3. MEET CB (IEC 60950 ) 4.
  • Page 8 G11233050...
