SilverStone Gemini Series Manual

80 plus platinum 800w 2u crps redundant power supply
Hide thumbs Also See for Gemini Series:

Advertisement

Quick Links

Download this manual
Gemini Series
Gemini 800C Platinum
80 Plus Platinum 800W 2U CRPS
Redundant Power Supply
800W+800W 24hour and well working performance at 45°C fully continuous power output
2U CRPS form factor: 82mm (W) x 102mm (H) x 245mm (D)
80 Plus Platinum certification
Active PFC (full range)
All Japanese electrolytic capacitors
Hot swappable design

Advertisement

loading
Need help?

Need help?

Do you have a question about the Gemini Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SilverStone Gemini Series

Summary of Contents for SilverStone Gemini Series

  • Page 1 Gemini Series Gemini 800C Platinum 80 Plus Platinum 800W 2U CRPS Redundant Power Supply 800W+800W 24hour and well working performance at 45°C fully continuous power output 2U CRPS form factor: 82mm (W) x 102mm (H) x 245mm (D) 80 Plus Platinum certification...

  • Page 2: Specification

    SPECIFICATION SilverStone Gemini Series Gemini 800C Platinum SST-GM800C-PF/SST-GM800C-PFU 1+1 2U CRPS Redundant Switching Power Supply 80 PLUS Platinum efficiency certified. 800W+800W 1.0 Introduction This specification defines the electrical and functional characteristics for two 800W Power modules .Unless otherwise noted, the requirements in this specifi- cation are applicable for each of the above listed power supplies.

  • Page 3: Output Power

    ※1. At 264Vac 25 , max load cold start, any Inrush current spike shall not °C exceed 35A peak. ※2. At 90~264Vac 25 , max load hot start, any inrush current of the AC line °C shall not cause damage to the power supply. 2.2 Efficiency Only power module efficiency meet Cybenetics Platinum at all specified load points.
  • Page 4 3.3 Dynamic Loads The output voltages shall remain within limits specified for the step loading and capacitive loading specified in the test table below. The load transient repetition rate shall be tested between 50Hz and 5KHz frequency and above 25% load. Output Step load Load slew rate...
  • Page 5 Output Min. Max. +12V 500uF 18000uF 400uF 5000uF +3.3V 250uF 5000uF -12V 350uF +5Vsb 20uF 350uF 4.0 Protection If the power supply is protected when OCP, OVP, OTP or short protection (except +5Vsb), the power supply shall shut down and latch off. The power supply return to normal operation after the fault condition has been remove and PS_ON signal must reset for OFF/ON cycle with a minimum OFF time of 1 second or AC power must reset for OFF/ON cycle with a minimum OFF time...
  • Page 6 4.4 Short Circuit Protection An output short circuit is defined as any output impedance of less than 10m Ω. The power supply shall shut down and latch off for shorting the +3.3V, +5V, or +12V rails to return. The +5Vsb power supply will not latch under short circuit condition on +5Vsb output.
  • Page 7 5.0 Sequencing and Signals AC ON T1: 1.5S MAX T7: 50ms MIN +5Vsb T2: 0.1～70ms PS ON 12ms MIN T6: 400ms MAX Outputs T5: 1ms MIN +12V, +5V, +3.3V T2: 0.1～70ms T5: 1ms MIN T4: 10ms MIN PWOK T3: 100ms～500ms T1: +5Vsb power on delay time ≦...
  • Page 8 The electrical and timing characteristics of the PWOK signal are given in below. Signal type +5V TTL compatible ＜ 0.4V while sinking 4 mA Logic level low Logic level high Between 2.4V and 5.25V output while sourcing 200 uA High state output impedance 1KΩ...

  • Page 9: Redundant Operation

    5.6.1 Address (ADDR) The PMbus device address locations are shown below. PMBUS Address FRU Address Binary Binary PSU1 1011 0000 1010 0000 PSU2 1011 0010 1010 0010 5.6.2 SCL and SDA SCL and SDA comprise a bi-directional serial data bus used to commu- nicate between the SMBus devices with-in the power supply and the host system.
  • Page 10 7.2.2 Electrostatic Discharge Immunity Test (ESD) Meet IEC61000-4-2 level 4, Criteria A for contact +/- 8KV and air +/-15KV. 7.2.3 Radio Frequency Electromagnetic Field Immunity Test (RS) Meet IEC61000-4-3 level 3, Criteria A for 80~1000MHz, 10V/m. 7.2.4 Electrical Fast Transient/Burst Immunity Test (EFT/BURST) Meet IEC61000-4-4 level 3, Criteria A for L to N 2KV 7.2.5 Surge Immunity Test Meet IEC61000-4-5 level 3, L to N 1KV, line to Earth 2KV, Criteria A.
  • Page 11 8.0 Environment 8.1. Temperature 8.1.1 Operation temperature of the supply will be between 0 to 45 °C °C 8.1.2 Storage temperature of the supply will be -40 to +80 °C °C 8.2. Humidity 8.2.1 Operation relative humidity of the supply will be between 10% and 90% (non-condensing).

  • Page 12: Serial Bus Commands

    11.0 Serial Bus Commands This feature only the power module (TG17-0800-01) support Code Command Bytes Read / Write 01h Operation Read / Write 03h Clear_Faults Write 05h Page_Plus_Write Variable Block Write 06h Page_Plus_Read Variable Block Write – Block Read Process Call 19h Capability Read 1Ah Query...
  • Page 13 11.2 PMBus Command Summary PMBus commands are one byte command codes. As below listing is power supply can support of PMBus commands. 11.2.1 Read commands The READ commands allow the host to read temperature, current, voltage, power and energy parameters of the power supply. PMBus command Description Data format...
  • Page 14 Accuracy Accuracy Pin < 100W Pin > 100W Read_Vin ±5% Read_Iin ±0.1A ±5% Read_Pin ±10W ±5% Read_Vout ±5% Read_Iout ±0.5A ±5% Read_Pout ±10W ±5% Read_Temperature_1 ±5℃ Read_Temperature_2 ±5℃ Read_Temperature_3 ±5℃ <9000rpm±1000rpm; >9000rpm±2000rpm Read_Fan speed 11.2.2 Capability and inventory reporting The follow commands shall be supported for discovery of the power supplies capabilities.
  • Page 15 11.2.5 Coefficients This command is used to retrieve the m, b and R coefficients needed by data in the DIRECT format. 11.2.6 Status commands Status information is binary. A value of 1 indicates a fault or warning event has occurred and a value of 0 indicates that a fault or warning event has not occurred.
  • Page 16 The Status_Vout (7Ah) command returns one data byte with contents as below: Bits Meaning +12V output voltage exceed 14V has occurred (Fault) +12V output voltage exceed 13.2V has occurred (Warning) +12V output voltage less than 10.8V has occurred (Warning) +12V output voltage less than 10V has occurred (Fault) Not support, set to 0 The Status_Iout (7Bh) command returns one data byte with contents as below: Bits...
  • Page 17 The Status_CML (7Eh) command returns one data byte with contents as below: Bits Meaning Invalid Or Unsupported Command Received Invalid Or Unsupported Data Received Packet Error Check Failed Not support, set to 0 Reserved, read 0 Not support, set to 0 The Status_Fans (81h) command reports on the status of fans installed in position Bits Meaning...
  • Page 18 Product area format version Product header Product area length Language (English) Manufacturer name / length Model number / length Customer information (max 15 bytes) Customer Name X： ASCII code X： ASCII code X： ASCII code X： ASCII code X： ASCII code X：...
  • Page 19 X： ASCII code X： ASCII code Product version / length X：From A to Z To be updated X：From 0 to 9 To be updated X：Reserve To be updated Product serial number / length X：T = LEAD YEAR, M = SMART, C = AMAX To be updated X：For LEAD YEAR model code (2 bytes) X：Year (00~99) date code...
  • Page 20 Peak VA (2 bytes) 1320W Inrush current Inrush interval in ms 10ms Low end Input voltage range 1 100V High end Input voltage range 1 240V Low end Input voltage range 2 High end Input voltage range 2 264V Low end Input frequency range 47Hz High end Input frequency range 63Hz...
  • Page 21 Maximum output current DC output Multirecord Record format version Header Record length Record checksum Header checksum Output number 2 +12Vsb Nominal voltage Maximum negative voltage 11.4V Maximum positive voltage 12.6V Ripple and noise pk-pk 10Hz to 20MHz 120mV Minimum output current Maximum output current 2.1A Don't used...
  • Page 22 A single PCIe 8pin cable and connector’s maximum current rating is Anschlusses beträgt 12,5 A, was 150 W (+12 V x 12,5 A) entspricht. 12.5A, which is 150W (+12V x 12.5A). So SilverStone’s warranty will not Daher deckt die SilverStone-Garantie keine Schäden oder...
  • Page 23 électrique asegúrese de que los dispositivos conectados funcionan dentro de estos límites. La garantía de SilverStone no cubrirá daños o fallos a Le courant nominal maximum d'un câble et d'un connecteur PCIe 8 resultas de un uso excesivo de estos conectores y sus cables broches unique est de 12,5 A, ce qui correspond à...
  • Page 24 (+12V x 5A x 2) โปรดตรวจสอบให้ ม ั ่ น ใจว่ า อุ ป กรณ์ ต ั ว ดึ ง พลั ง งาน +12V ที ่ เ ชื ่ อ ม ต่ อ กั บ เมนบอร์ ด สามารถทำงานภายใต้ ข ี ด จำกั ด เหล่ า นี ้ ไ ด้ การรั บ ประกั น ของ SilverStone ไม่...
  • Page 25 (2) this device must accept any interference received, including interference that may cause undesired operation. the power supply is only suitable for Information Technology & Audio/Video equipment. Model (safety certification) : SST-CS0800FCPT-A ※付属の電源コードは当該製品専用です。他の機器に使用しないでください。 Please refer to SilverStone website for latest specifications updates.
