Reese Towpower 78115 Installation Instructions

READ THIS FIRST:
Read and follow all instructions
carefully before beginning
installation.
LISEZ CECI EN PREMIER:
Lire et suivre toutes les
instructions
attenrivement avant le
montage.
LEA ESTO PRIMERO:
Lea y siga todas las
instrucciones cuidadosa-mente
antes de iniciar la instalación.
INSTRUCTIONS:
1. Insert wires through holes and place them on
the splicer/ contacts (see ill. A).Make sure to
match the color coding.
2. Close cover with pliers. (see ill. B) Attach the
2 screws (included).
3. Use the built-in tester to confirm the circuits
are connected properly.
4. Install Dust Cover( included).
NOTE:
.
 Vehicles with separate turn and stop lights require a taillight converter.
 lf splicing into the vehicle wiring, check the vehicle owner's manual and/or
local dealer for any warnings or restrictions before splicing. When splicing
use appropriate gauge wire splices.
WARNING
All connections must be complete to function properly. Test and verify installation
with a test light, circuit tester or trailer once installed.
WARNING
Overloading circuit can cause fires. DO NOT exceed lower of towing manufacturer
rating or:
 Max. Right Turn, Left Turn, Stop, & Tail Light Circuits: (7.5 amps)
 Max. (+) Battery, Reverse, and Electric Brake Circuits: (30 amps)
Read vehicle's owners manual & instruction sheet for additional information.
Additional fusing may be required.
Cequent Consumer products
29000-2 Aurora Road
Solon, OH 44139
www.cequentconsumerproducts.com
lnstallation lnstructions
lnstrucciones de instalación
Directives de montage
Insta-Plug Connector
P/N 78115
12/12
