Sainlogic WS0835 Plus Quick Setup Instructions

Email: info@sainlogic.com
1. Install Batteries for Outdoor Sensor Array first.
Remove the battery door on the
back of the sensor by removing the
set screw.
2. Plug in Adapter for Indoor Console second.
Pull out the stand on the back.
Connect the indoor
console with power
adaptor.
Don't press any
button until outdoor
data is received.
Outdoor Sensor Data Updates
No Outdoor Sensor Data
Sainlogic WS0835 Plus Weather Station Quick Setup Instruction
Website:www.sainlogic.com
Inserting 3xAA batteries in the
battery compartment.
3. Sensors Verification Before Installation
Put the outdoor sensor array and the indoor console
at the same location in good ventilating condition.
1. Verify temperature and humidity. The difference
between indoor and outdoor temperatures should be
within 4°F/2°C. The difference between indoor and
outdoor humidity should be within 10%. Usually the
indoor temperature is a little bit higher than outdoor
temperature due to warming up effect of the
backlight. Let the unit stabilize for at least 30
minutes.
2. Verify wind speed and wind direction. Spin the
wind cup and the wind vane and make sure the wind
speed and wind direction information on display
updates.
3. Verifying Rain gauge. Tip the sensor array back
and forth several times. You should hear a "clicking"
sound within the rain gauge. Verify the rain reading
on the display console is not reading 0.00. Each
"click"represents 0.01 inches of rainfall.
Face solar panel to south in Northern Hemispheres
installation.
Face solar panel to north in Southern Hemispheres.
Skype: sainlogic@outlook.com
Close the battery door and Tighten the set screw. The sensor LED
indicator will light and flash every 16s.
4. Outdoor Integrated Sensor Installation
Please ensure that the outdoor transmitter is fixed particularly tightly,
otherwise windy conditions cause the transmitter to shake and thus
misread the rainfall data.
I nstall the sensor array at least four times the distance of the
height of the tallest obstruction.
- 1 -
Whatsapp: +44 7475380745
Note: Make sure the red LED flashes each 16 seconds. If
not, check whether batteries are installed correctly.
Horizontal Installation
Vertical Installation
