Delta BH2001 Assembly Instructions

Crossbar
Substitute
Assembly instructions
Open Quick release clamp (FIGURE 1)
1
then adjust crossbar substitute length
to desired t. (Distance between hooks:
Max 32.25" / Min 23")
Place hooks around seat post
2
and handlebar stem.
WARNING
Do not exceed Max Load: 50 lb (22.7 kg)
Incorrect installation could result in an accident causing serious injury.
Failure to use strap may result in loss of bicycles.
BH2001
OPEN POSITION
FIGURE 1
Close quick release clamp.
3
Ensure locking lever is fully
closed during transport.
IMPORTANT SAFETY NOTE
When mounting to rear bike rack,
be sure to use the bike rack straps
to secure the crossbar.
CLOSED POSITION
071822
