Delta Thru-Axle Hitch Pro Assembly Instructions

Thru-Axle Hitch
Assembly instructions
Parts
A
x1 — Base
B
x2 — 12mm Inserts
C
x2 — 15mm Inserts
D
x2 — Locking Nuts
x1 — Roof Rack Adaptor
E
( ts 9 and 12mm axles)
F
x2 — Bolts
G
x2 — Nuts
Tool Required
Allen Key
For 135, 145, 150mm Widths (15mm)
Screw the locking nuts onto the
1
inserts past the three lines.
135mm
145mm
150mm
For 100mm Widths
(12 and 15mm)
1
Use only the insert required tightened
ush to outer end of base.
WARNING
The Bike Hitch Pro is designed to hold a bicycle only and has not been designed to support a rider
and should never be used with a person on the bike.
BH6002-PRO
A
E
Screw the insert into the base up until
2
the desired width line is ush with the
base. 135 (outer line), 145 (middle line)
and 150 (inner line).
For 110mm Widths
(15mm)
Use the insert required with lock nut
1
tightened ush to outer end of base.
Pro
™
B
3
Base Adapter
Attachment
1
C D F
Screw the locking nut towards the base
and tighten against base until secure.
Use allen key to bolt base to
roof rack adaptor as shown.
G
