Federal regulations require all ceiling

fans with light kits manufactured or

imported after January 1, 2009, to limit

total wattage consumed by the light kit

to 190W. Therefore, this fan is equipped

with a wattage limiting device.

Installation Guide

For model:

E-BLR44ABZ5C

E163438

net weight of fan: 13.91 lb. (6.31 kg)

READ THESE INSTRUCTIONS AND

SAVE THEM FOR FUTURE USE

Need help?

Do you have a question about the E-BLR44ABZ5C and is the answer not in the manual?

Questions and answers

Summary of Contents for Litex Industries E-BLR44ABZ5C

Page 1: Table Of Contents
190W. Therefore, this fan is equipped with a wattage limiting device. Installation Guide For model: E-BLR44ABZ5C Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation.
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. Read all instructions and safety information carefully before installing your fan and save these instructions. CAUTION: To avoid personal injury, the use of gloves may be necessary while handling fan parts with sharp edges.
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches that the hanging location allows the blades a 7 feet (76cm) clearance of 7ft. (2.13m) from the floor and 30in. (2.13m) (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 225 square feet (20.9 square meters).
Page 5 5. Fan Assembly (with downrod). set screw hole If you wish to extend the hanging length of your set screw fan, you must remove the hanging ball from the stop pin 4in. downrod provided to use with an extended downrod (sold separately). [If you wish to use the 4in.
Page 6: Fan Assembly. Pgs
5. Fan Assembly (with downrod). (cont. ) With the hanging bracket secured to the outlet box and able to support the fan you are now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging bracket and let hanging ball rest on the hanging hanging bracket tab bracket.
Page 7: Wiring
7. Wiring. white supply wire ground Important: Be sure outlet box is properly grounded (green or bare) or that a ground wire (GREEN or Bare) is present. black supply wire Make sure all electrical connections comply with Local Codes or Ordinances and the National from ceiling Electrical Code.
Page 8: Blade Assembly
9. Blade Assembly. Time Saver: Washers for blade screws can be motor housing set on each blade screw prior to installing blades. Locate 15 blade attachment screws and washers in one of the hardware packs. Hold blade arm up to blade and align holes. Insert 3 blade attachment screws (along with washers) blade with fingers first and then tighten screws...
Page 9: Testing Your Fan
11. Testing Your Fan. It is recommended that you test fan before finalizing installation. Restore power from circuit box and light switch (if applicable). Test motor housing fan speeds with pull chain on switch housing. Start at the OFF position (no blade movement). First pull will set the fan to HI.
Page 10: Troubleshooting
Service at 1-800-527-1292 to arrange for return of fan. 1. Check wall switch to fan. Return fan, shipping prepaid, to Litex Industries, Ltd. We will 2. Verify that reverse switch is set completely in repair or ship you a replacement fan, and we will pay the either direction.
