  • Page 1 SHP-30K-400CP Installation manual Security Industrial Automate Telecom 30KW HVDC Power Supply High efficiency Intelligent...
  • Page 2 The SHP-30K-400CP is a 30KW high-efficiency AC/DC power supply that operates with a 3-phase, 3-wire AC input across a wide voltage range. The series supports ambient temperatures up to 70°C with forced air cooling. Additionally, the SHP-30K-400CP offers extensive design flexibility with various built-in functions, including: Output voltage/current programming, active current sharing, remote ON/OFF control, auxiliary power, and external communication.

  • Page 3: Table Of Contents

    Contents 1.Safety Guidelines 6.Communication Protocol PMBus Communication 2.Introduction Interface 2.1 Model Encoding 6.2 CANBus Communication 2.2 Features Interface 2 3 Specification 6 3 . us Communication 2 4 Derating curve Interface 2 5 . Mechanical specification Value range and tolerance 3.Installation &...

  • Page 4: Safety Guidelines

    -MOD MODBus-RTU/RS-485 By request WARNING: The SHP-30K-400CP may generate high leakage current when operated with three-phase three-wire (Δ) input. It is essential to specify the leakage current value in the final system and its user manual and also incorporate the following warning symbols within them.

  • Page 5: Features

    ψ 3-wire / or Y 340~530VAC or 3 ψ 4-wire / Y 340~530VAC MODEL SHP-30K-400CP DC VOLTAGE (factory default) 400V High efficiency up to 9 % CURRENT (factory default) 2U high 19"-inch rack with forced air cooling RATED RANGE 0 ~ 103.5A RATED POWER (max.)

  • Page 6: 4 Derating Curve

    erating curve SAFETY STANDARDS UL62368-1, CAN/CSA C22.2 No. 62368-1 , TUV BS EN/EN62368-1 EAC TP TC 004 a pproved WITHSTAND VOLTAGE I/P-O/P:4.25KVAC I/P-FG:3KVAC O/P-FG:3KVAC Note.4 ℃ ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH Note.4 Parameter Standard Test Level / Note...

  • Page 7: 5 . Mechanical Specification

    MAX. Penetration Depth Recommended mounting torque 7~1 Kgf-cm (Front View) (Side View) (Back View) Mounting Screw Item Description Item Description CMU2 Smart Controller AC Input Circuit Breaker SHP-30K-400CP Power Supply DC Output Terminal 30U Cabinet AC Input Terminal Block RJ-45 port...

  • Page 8: Installation Notes

    ◎ 3φ3-wire / △ 340VAC~530VAC system from the utility. Ensure that it cannot be re-connected to the SHP-30K-400CP utility inadvertently. B. Keep enough insulation distance between mounting screws and internal components of power supplies. Please refer to 2.5 Mechanical specification to receive the maximum length of mounting screw C.

  • Page 9: Panel And Led Indicator

    4.Panel and LED Indicator 4.2 Pin Assignment of CN53 4.1 Panel Description -V(Signal) -V(Signal) AC input terminals: M6 screws are used; Recommended cable size: 3 - 10 AWG ; Recommended torque: 18kgf-cm. DC output terminals: M8 screws are used; Please refer to Section 3.3 for cable suggestion. Recommended torque: 80kgf-cm for the accessories come with the power supply.

  • Page 10: Communication Address

    4. Communication Address/ID Assignment Pin No. Function Description Each SHP 30K 400CP unit should have their unique and own device address to communicate over Short: Termination resistors(120 ) For CANBus MODBus Ω 、 、 the CANBus, PMBus or MODBus . SW51 and S 52 allow users to designate an address or ID for the...

  • Page 11: Operation

    5. .2 PV (Output Voltage Programming) Switch position Switch position Address/ID Address/ID A.Set DIP switch 3 to ON position SW51 SW52 SW51 SW52 1 2 3 B.Connect output of external DC source to PV+ and -V(signal) as shown in Figure 5-2. C.Relationship between output voltage and external DC source is shown in Figure 5-3.

  • Page 12: Output Current Adjustment

    Iout Vout 5. .3 Communication Output voltage can be adjusted through communication interfaces: 30KW PMBus, CAN us or M us. Please refer to chapter 6 for detailed constant power curve information. Non-Linear Output Current Adjustment Output current can be adjusted via PC and communication interface. ●...

  • Page 13: Remote Control

    Remote Control 5. . 5 2 SHP-30K-400CP has the built-in active current sharing function and can be connected in parallel, up to 12 units or more, to provide higher output power as exhibited below : The power supply can be turned ON-OFF by using the "Remote ●...

  • Page 14: Auxiliary Output

    Auxiliary Output 6.Communication Protocol uilt-in 12V/1. A auxiliary output ● There are two means to control the unit, analog signals and digital ● communication. Analog is the default setting for the unit, signals including PV, PC and SVR can be used immediately once receiving the unit.
  • Page 15 ◎Definition of Table 6-1 Command BEh SYSTEM_CONFIG Command Command Transaction # of data Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 Page Description Code Name Type Bytes High byte EEP_OFF EEP_CONFIG PAGE R/W Byte Page OPERATION R/W Byte Remote ON/OFF control Low byte OPERATION_INIT PM_CTRL...
  • Page 16 The Voltage, in volts, is calculated from the equation: Voltage V SDA(CN86) Where: Voltage is the parameter of interest in volts; Controllor SCL(CN86) SHP-30K-400CP V is a 16 bit unsigned binary integer; and N is a 5 bit two' complement binary integer. GND-AUX(CN86)

  • Page 17: Canbus Communication

    0x40 Write 0x22 0x80, 0x02 Max. response time (SHP-30K-400CP to Controller): 12.5mSec 。 Command code: 0x22(VOUT_TRIM) Min. packet margin time (Controller to SHP-30K-400CP): 12.5mSec 。 Data: 1 V → → 0x 0(Lo) + 0x0 (Hi) Request period NOTE: VOUT_TRIM is LINEAR16 forma...
  • Page 18 6.2.1 Message ID definition 6.2.2 Command list Message ID Description Command Command Transaction # of data Description Code Name Type Bytes 0x000C00XX SHP to Controller Message ID ON/OFF control 0x0000 OPERATION 0x000C01XX Controller to SHP Message ID ON: 01h/OFF: 00h 0x000C01FF Controller broadcasts to SHP Message ID(Writing only) Output voltage set...
  • Page 19 Bit 6 OP_OFF：DC status Command Command Transaction # of data Description 0＝DC output turned on Code Name Type Bytes 1＝DC output turned off Manufacture date 0x0086 MFR_DATE_B0B5 Manufacture serial number 0x0087 MFR_SERIAL_B0B5 Bit 7 HI_TEMP：Internal high temperature alarm Manufacture serial number 0＝Internal temperature normal 0x0088 MFR_SERIAL_B6B11...
  • Page 20 Bit 4:7 IOUT Factor：The Factor of DC current ◎MFR_DATE_B0B5 ( 0x0086 ) is manufacture date (ASCII) 0x = Output current relevant commands not supported MFR_DATE_B0B5 is 180101, meaning 2018/01/01 0x4=0.001 Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 0x5=0.01 0x31...
  • Page 21 ◎SYSTEM_CONFIG byte3: (0x00C2)： Bit 0:3 IIN Factor：The Factor of AC input current Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 0x = AC input current relevant commands not supported High byte EEP_OFF EEP_CONFIG 0x4=0.001 Low byte OPERATION_INIT CAN_CTRL 0x5=0.01 Low byte: 0x6=0.1 Bit 0 CAN_CTRL：CANBus communication control status...
  • Page 22 CN86 connector are short-circuited if there is no output voltage. ◎If the unit is a terminal, it is recommended to connect a termination resistor, that is short circuit PIN1 and PIN 2 of CN86. CN86 +5V-AUX PIN15 CN86 CANH SHP-30K-400CP PIN1 (CN86) PIN2 (CN86) Controllor 120Ω Remote ON-OFF SHP-30K-400CP 120Ω...

  • Page 23: 3 . Modb Us Communication

    6 3 . us Communication Interface 6.3.3 Additional Address Definition Additional address is the slave ID of the device. Each SHP- 0K- 400CP The device supports M us RTU with the master-salve principle. unit should have their unique and own device address to Users are able to read and write parameters of the device through communicate over the bus.
  • Page 24 Table Register Command Function # of data Description address Name code Bytes Register Command Function # of data Description address Name code Bytes Manufacture model name 0x0086 MFR_MODEL_ 0x03 Remote ON/OFF control 0x0000 OPERATION 0x03、0x06 B0B5 ON: 0x0001 Manufacture model name 0x0089 MFR_MODEL_ 0x03...
  • Page 25 ' (ASCII); MFR_MODEL_B6B11(0x0089 - 0x008B) is the last 6 codes of the manufacturer s model ' name (ASCII) Bit 3 OLP：Output over current protection EX: Model name is SHP-30K-400CP → MFR_MODEL_B0B5 is SHP 30 ； 0＝Output current normal MFR_MODEL_B6B11 is K 400P 1＝Output over current protected...
  • Page 26 ◎SCALING_FACTOR (0x00C0) ： Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 0xFE 0x69 0xFF 0xFF 0xFF 0xFF Bit7~Bit0 byte4~5 Reserved ◎MFR_DATE_B0B5 (0x0091 -0x0093) is manufacture date (ASCII ) Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 EX: MFR_DATE_B0B5 is 180101 , meaning 2018/01/01...
  • Page 27 ◎SYSTEM_STATUS byte1: (0x00C3)： Bit 0:3 VIN Factor：The Factor of AC input voltage Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 0x0=AC input relevant commands not supported High byte 0x4=0.001 INITIA- Low byte EEPER DC_OK ADL_ON PFC OK M S / LSTATE 0x5=0.01 0x6=0.1...
  • Page 28 .3. .2 Read Input Register (FC=04) OPERATION_INIT：Pre-set value of power on operation command The request message specifies the starting register and quantity 0b00＝Power OFF, pre-set 0x00(OFF) 0b01＝Power ON, pre-set0x01(ON) (factory default) of registers to be read. For example: The master requests the 0b10＝Pre-set is previous set value content of analog input register 0x0060 READ_VOUT...
  • Page 29 0x9BD1 resistor, that is short circuit PIN1 and PIN2 of CN86. PIN15 CN86 DATA+ The unit returns data below PIN1 (CN86) PIN2 (CN86) Controllor 120Ω SHP-30K-400CP Slave Function The number of data 120Ω Data DATA- Address Code bytes to follow...

  • Page 30: Value Range And Tolerance

    Value range and tolerance (2)Control parameters (1)Display parameters Display value range Tolerance Default PM: 00h OFF 01h ON Display value range Tolerance OPERATION CAN/MOD: 00h OFF 01h ON READ_VIN 340~530V ±10V VOUT TRIM -250 50V ±4 0V PMBus only READ_IIN 0~54A ±0.81A 150 450V...

  • Page 31: Protections And Trouble

    If you are unable to clarify the problem you are facing, please contact MEAN WELL or any of our distributors for repair service. mode to prevent damaging itself. The supply will restore automatically when AC voltage is back to a normal range.

  • Page 32: Warranty

    ※ MEAN WELL possesses the right to adjust the content of this manual. Please refer to the latest version of manual on our website. https://www.meanwell.com...
