Mean Well SHP-30K-HV Series Installation Manual

30kw hvdc power supply, high efficiency, intelligent
Hide thumbs Also See for SHP-30K-HV Series:

Advertisement

Quick Links

Download this manual
SHP-30K-HV Series
Installation manual
Security
Industrial
EV
Automate
Telecom
30KW HVDC Power Supply
High efficiency
Intelligent

Advertisement

loading
Need help?

Need help?

Do you have a question about the SHP-30K-HV Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mean Well SHP-30K-HV Series

Summary of Contents for Mean Well SHP-30K-HV Series

  • Page 1 SHP-30K-HV Series Installation manual Security Industrial Automate Telecom 30KW HVDC Power Supply High efficiency Intelligent...
  • Page 2 SHP-30K-HV series is a 30KW high efficiency AC/DC power supply. This series operates for the wide range three phase AC input n eutral is not needed, and offers the models with DC outputs (55V/115V/230V/380V) that mostly demanded by various industries. Can be working at ambient temperature up to 70 ℃...
  • Page 3 Contents 1.Safety Guidelines 6.Communication Protocol PMBus Communication 2.Introduction Interface 2.1 Model Encoding CANBus Communication 2.2 Features Interface 2 3 Specification 6 3 . us Communication 2 4 Derating curve Interface 2 5 . Mechanical specification Value range and tolerance 3.Installation & Wiring 7.Protections and Trouble 3.1 Mounting Shooting...
  • Page 4 1.Safety Guidelines 2.Introduction 2.1 Model Encoding Risk of electrical shock and energy hazard, all failure should be examined by a qualified technician. Please do not remove the case form the power supply by SHP - yourself. Please do not change any component on the unit or make any kind of Communication protocol option modification on it.
  • Page 5 Features Specification △ ψ 3-wire / or Y 340~530VAC or 3 ψ 4-wire / Y 340~530VAC MODEL SHP-30K-55 SHP-30K-115 SHP-30K-230 SHP-30K-380 DC VOLTAGE (factory default) 55V 115V 230V 380V High efficiency up to 9 % CURRENT (factory default) 346A 261A 130.5A Up to 120% peak power capability RATED RANGE...
  • Page 6 erating curve MODEL SHP-30K-55 SHP-30K-115 SHP-30K-230 SHP-30K-380 SAFETY STANDARDS UL62368-1, CAN/CSA C22.2 No. 62368-1 , TUV BS EN/EN62368-1 EAC TP TC 004 a pproved WITHSTAND VOLTAGE I/P-O/P:4.25KVAC I/P-FG:3KVAC O/P-FG:1.25KVAC I/P-O/P:4.25KVAC I/P-FG:3KVAC O/P-FG:3KVAC Note.4 ℃ ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH Note.4 Parameter Standard...
  • Page 7 2.5 Mechanical specification 3.Installation & Wiring Mounting 3.1.1 Normal Mounting 40 max. Suggested mounting on horizontal surfaces. CN53 CN86 4-M4 L=5mm 68.75 SW51 SW52 433.9 SW51 SW52 CN86 1 2 3 CN53 DIP-SW Horizontal mounting 4-M4 L=5mm 3.1.2 System power cabinet Air flow direction (TOP View)
  • Page 8 Installation Notes AC Power Connection A. Before any installation or maintenance work, please disconnect your ◎ / △ 3φ3-wire 340VAC~530VAC system from the utility. Ensure that it cannot be re-connected to the SHP-30K-HV utility inadvertently. B. Keep enough insulation distance between mounting screws and internal components of power supplies.
  • Page 9 4.Panel and LED Indicator Pin Assignment of CN53 Panel Description -V(Signal) -V(Signal) AC input terminals: M6 screws are used; Recommended cable size: 3 - 10 AWG ; Recommended torque: 18kgf-cm. DC output terminals: M8 screws are used; Please refer to Section 3.3 for cable suggestion. Recommended torque: 80kgf-cm for the accessories come with the power supply.
  • Page 10 4. Communication Address/ID Assignment Pin No. Function Description Each SHP 30K HV unit should have their unique and own device address to communicate over the Short: Termination resistors(120 ) For CANBus MODBus Ω 、 、 CANBus, PMBus or MODBus . SW51 and S 52 allow users to designate an address or ID for the...
  • Page 11 5.Operation Inrush Current Limiting Built-in AC inrush current limiting circuit. ● Peak Power Since the inrush current limiting circuit mainly consists of a NTC ● The SHP-30K can provide up to 120% peak power output. As long as the load cycle thermistor and a relay, inrush current will be much higher than the conditions meet the formula below, the product should not trigger over-temperature, specified value if the thermistor is not allowed sufficient time to...
  • Page 12 5. .2 PV (Output Voltage Programming) 5. .3 Communication A.Set DIP switch 3 to ON position Output voltage can be adjusted through communication interfaces: PMBus, CAN us or M us. Please refer to chapter 6 for detailed 1 2 3 information.
  • Page 13 Iout 5. . 6 2 SHP-30K-HV has the built-in active current sharing function and can be connected in parallel, up to 12 units or more, to provide higher output power as exhibited below : ◎ The power supplies should be paralleled using short and large diameter wiring and then connected to the load.
  • Page 14 Remote Control Auxiliary Output The power supply can be turned ON-OFF by using the "Remote uilt-in 12V/1. A auxiliary output ● ● ON-OFF" function. CN86 CN86 CN53 CN53 SW51 SW51 SW52 SW52 PIN19 & 20 GND-AUX Figure 5 10 PIN3 Remote ON-OFF PIN4 +5V-AUX PIN17 &...
  • Page 15 Table 6-1 6.Communication Protocol Command Command Transaction # of data Page Description There are two means to control the unit, analog signals and digital ● Code Name Type Bytes PAGE R/W Byte Page communication. Analog is the default setting for the unit, signals OPERATION R/W Byte Remote ON/OFF control...
  • Page 16 ◎Definition of Command BEh SYSTEM_CONFIG Bit 2: P _OK : Primary PFC status Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 0＝Primary PFC OFF or abnormal High byte EEP_OFF EEP_CONFIG 1＝Primary PFC ON normally Low byte OPERATION_INIT PM_CTRL Bit 4 ADL_ON : Active dummy load control status Low byte 0＝Active dummy load off Bit 0 PM_CTRL: PMBus...
  • Page 17 For example: 3.Configure communication settings after power on. Enable Vo_real (actual output voltage) = V x 2 , V is from READ_VOUT. communication mode and set power ON when AC connected. If VOUT_MODE = 0x17, meaning N is -9. READ_VOUT is 0x3000 →...
  • Page 18 6.2.1 Message ID definition CANBus Communication Interface Message ID Description Physical layer specification ● This protocol follows CAN ISO-11898 with Baud rate of 250Kbps. 0x000C00XX SHP to Controller Message ID Data Frame ● 0x000C01XX Controller to SHP Message ID This protocol es Extended CAN 29-bit identifier frame format or 0x000C01FF Controller broadcasts to SHP Message ID(Writing only)
  • Page 19 6.2.2 Command list Command Command Transaction # of data Description Code Name Type Bytes Command Command Transaction # of data Description Code Name Type Bytes Manufacture date 0x0086 MFR_DATE_B0B5 ON/OFF control Manufacture serial number 0x0000 OPERATION 0x0087 MFR_SERIAL_B0B5 ON: 01h/OFF: 00h Manufacture serial number 0x0088 MFR_SERIAL_B6B11...
  • Page 20 ◎MFR_DATE_B0B5 ( Bit 6 OP_OFF：DC status 0x0086 ) is manufacture date (ASCII) 0＝DC output turned on MFR_DATE_B0B5 is 180101, meaning 2018/01/01 1＝DC output turned off Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Bit 7 HI_TEMP：Internal high temperature alarm 0x31 0x38...
  • Page 21 Bit 4:7 IOUT Factor：The Factor of DC current byte3: 0x = Output current relevant commands not supported Bit 0:3 IIN Factor：The Factor of AC input current 0x4=0.001 0x = AC input current relevant commands not supported 0x5=0.01 0x4=0.001 0x6=0.1 0x5=0.01 0x7=1.0 0x6=0.1 0x8=10...
  • Page 22 ◎SYSTEM_CONFIG .2. .2 Reading data or status (0x00C2)： The master reads operation setting from the unit with address "00". Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 High byte EEP_OFF EEP_CONFIG CAN ID DLC (data length) Command code Low byte OPERATION_INIT CAN_CTRL 0x000C0101...
  • Page 23 4.Set Output voltage to 56V 6 3 . us Communication Interface The device supports M us RTU with the master-salve principle. CAN ID Operation Command Code Data Users are able to read and write parameters of the device through 0x000C0100 0x04 0xE015 the protocol, including remote ON/OFF, output voltage/current...
  • Page 24 6.3.3 Additional Address Definition Table Additional address is the slave ID of the device. Each SHP- 0K- Register Command Function # of data Description address Name code Bytes unit should have their unique and own device address to communicate over the bus. Remote ON/OFF control 0x0000 OPERATION...
  • Page 25 ◎FAULT_STATUS (0x0040)： Register Command Function # of data Description address Name code Bytes Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 High byte Manufacture model name 0x0086 MFR_MODEL_ 0x03 Low byte B0B5 HI_TEMP OP_OFF AC_FAIL SHORT FAN FAIL Manufacture model name 0x0089 MFR_MODEL_ 0x03...
  • Page 26 ◎MFR_ID_B0B5 (0x0080 - 0x0082) is the first 6 codes of the Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 manufacturer's name (ASCII); MFR_ID_B6B11(0x0083 - 0x0085) is the 0xFE 0x69 0xFF 0xFF 0xFF 0xFF last 6 codes of the manufacturer's name (ASCII) EX: manufacturer's name is MEANWELL →...
  • Page 27 ◎SCALING_FACTOR (0x00C0) ： byte1: Bit 0:3 VIN Factor：The Factor of AC input voltage Bit7~Bit0 0x0=AC input relevant commands not supported byte4~5 Reserved 0x4=0.001 Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 0x5=0.01 byte3 Reserved IIN Factor 0x6=0.1 Bit7 Bit6 Bit5 Bit4 Bit3 Bit2...
  • Page 28 ◎SYSTEM_STATUS (0x00C3)： OPERATION_INIT：Pre-set value of power on operation command 0b00＝Power OFF, pre-set 0x00(OFF) Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 0b01＝Power ON, pre-set0x01(ON) (factory default) High byte 0b10＝Pre-set is previous set value INITIA- Low byte EEPER DC_OK ADL_ON PFC OK M S / 0b11＝not used, reserved LSTATE...
  • Page 29 .Connect the DATA+/DATA- pins of the master to the corresponding .3. .2 Read Input Register (FC=04) DATA+ (PIN15) and DATA- (PIN13)pins of the CN86 connector on the The request message specifies the starting register and quantity supply. It is recommended to establish a common ground for the of registers to be read.
  • Page 30 4.Set Output voltage to 56V. Value range and tolerance (1)Display parameters Data Address Slave Address Function Code Data of the registe Model Display value range Tolerance 0x00 0x06 0x0020 0x15E0 0x86C9 READ_VIN 340~530V ±10V 0x00: Slave ID 0 0x06: Function code 6 (Write Single Register) 0x0020: VOUT_SET register READ_IIN...
  • Page 31 (2)Control parameters 7.Protections and Trouble Shooting Model Display value range Tolerance Default Protections PM: 00h OFF 01h ON OPERATION CAN/MOD: 00h OFF 01h ON 7.1.1 Over Temperature Protection (OTP) and T Alarm Built-in thermal detection circuit, once the internal temperature 31~2 6V ±0.55V exceeds a threshold value, the supply will shut down automatically.
  • Page 32 Over Voltage Protection ※ MEAN WELL possesses the right to adjust the content of this manual. When the output voltage is too high, the over-voltage protection Please refer to the latest version of manual on our website. circuit will be triggered. Repower on to restore after over-voltage https://www.meanwell.com...
  • Page 33 N o . 2 8 , W u q u a n 3 r d R d . , W u g u D i s t . , N e w Ta i p e i C i t y 2 4 8 , Ta i w a n...
