SHP-10K-HV Series
Installation manual
Security
Industrial
EV
Automate
Telecom
10KW HVDC Power Supply
3φ3-wire wide input range
High efficiency
Intelligent

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SHP-10K-HV Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mean Well SHP-10K-HV Series

Summary of Contents for Mean Well SHP-10K-HV Series

  • Page 1 SHP-10K-HV Series Installation manual Security Industrial Automate Telecom 10KW HVDC Power Supply 3φ3-wire wide input range High efficiency Intelligent...
  • Page 2 SHP-10K-HV is a 10KW 3ψ 3W input AC/DC power supply. This series operates for the wide range three phase AC input (3 phase 3 wire / 340~530VAC) neutral is not needed, and offers the models with DC outputs (55V/115V/230V/380V) that mostly demanded by various industries.

  • Page 3: Table Of Contents

    Contents 1.Safety Guidelines 6.Communication Protocol PMBus Communication 2.Introduction Interface Model Encoding CAN Bus Communication Features Interface 2 3 . Specification 6 3 . Modbus Communication 2 4 . Derating curve Interface 2 5 . Mechanical specification Value range and tolerance 3.Installation &...

  • Page 4: Safety Guidelines

    1.Safety Guidelines 2.Introduction Model Encoding Risk of electrical shock and energy hazard, all failure should be examined by a qualified technician. Please do not remove the case form the power supply by SHP - yourself. Please do not change any component on the unit or make any kind of Communication protocol option modification on it.

  • Page 5: Features

    Features Specification 3φ3-wire without Neutral / 340~530VAC wide input range MODEL SHP-10K-55 SHP-10K-115 SHP-10K-230 SHP-10K-380 DC VOLTAGE (factory default) 55V 115V 230V 380V High efficiency up to 9 % CURRENT (factory default) 131A 43.5A 26.3A Water/ forced air cooling selectable RATED RANGE 0 ~ 150A 0 ~ 87A...

  • Page 6: 4 . Derating Curve

    erating curve SAFETY STANDARDS UL62368-1, CAN/CSA C22.2 No. 62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved WITHSTAND VOLTAGE I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.25KVAC Note.4 ℃ ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH Note.4 Blank Type Parameter Standard Test Level / Note...

  • Page 7: 5 . Mechanical Specification

    2.5 Mechanical specification Forced-Air Cooling (Blank type) 431.75 94.75 39.25 for 55V 4-M4 L=5mm for other 384.8 45.9 50 55 60 (HORIZONTAL) CN86 CN53 DIP-SW 4-M4 L=5mm AMBIENT TEMPERATURE WITH 85CFM FAN*2 Air flow direction Screw “A” (Note.4) 94.75 4-M4 L=5mm for other for 55V 18 max.

  • Page 8: Installation & Wiring

    3.Installation & Wiring Water Cooling (L type) Mounting 3.1.1 Normal Mounting The B lank type is suggested mounting on horizontal surfaces. Horizontal mounting 3.1.2 Mounting on a Water Cooled Plate CN86 CN53 A.L type with a water cooled plate for heat dissipation, it is suggested 257.5 DIP-SW LED SVR...

  • Page 9: Installation Notes

    Installation Notes B.Recommended settings for cooling water operating parameters. Ambient temperature: 50℃ A.Before any installation or maintenance work, please disconnect your Inlet temperature: 5~15℃ system from the utility. Ensure that it cannot be re-connected Flow rate (minimum): 4~ 10LPM inadvertently. Humidity: 20~90% RH non-condensing B.Keep enough insulation distance between mounting screws and Pressure drop 6 psi (minimum), pressure inlet 80 psi (maximum)

  • Page 10: Ac Power Connection

    AC Power Connection 4.Panel and LED Indicator ◎ / △ 3φ3-wire 340VAC~530VAC lank type 4.1.1 Panel Description SHP-10K AC input terminals DC output terminals DIP-SW1: Used for parallel control/PV/PC functions Function pins: They are used for control and monitoring functions. Please refer to 4.1.2 and 4.1.3.
  • Page 11 4.1.2 Pin Assignment of CN53 Pin No. Function Description The unit can turn the output ON/OFF by dry contact between Remote ON/OFF and +5-AUX.(Note) Remote Short (4.5 ~ 5.5V) : Power ON ; Open(0 ~ 0.5V) : Power OFF ; -V(Signal) -V(Signal) ON-OFF...

  • Page 12: L Type

    4.2 L type 4. .2 Pin Assignment of CN53 4. .1 Panel Description AC input terminals DC output terminals -V(Signal) -V(Signal) DIP-SW1: Used for parallel control/PV/PC functions Function pins: They are used for control and monitoring functions. Please refer to 4. .2 and 4. .3. LED indictor: Indicate the status of the supply and load condition.

  • Page 13: Operation

    5.Operation Pin No. Function Description The unit can turn the output ON/OFF by dry contact between Inrush Current Limiting Remote ON/OFF and +5-AUX.(Note) Remote Short (4.5 ~ 5.5V) : Power ON ; Open(0 ~ 0.5V) : Power OFF ; ON-OFF Built-in AC inrush current limiting circuit.

  • Page 14: Output Current Adjustment

    5.3.2 PV (Output Voltage Programming) 5.3.3 Communication A.Have the DIP switch position-3 set as Output voltage can be adjusted through communication interfaces: PMBus, CAN bus or Modbus. Please refer to chapter 6 for detailed 1 2 3 information. Output Current Adjustment B.Connect output of the external DC source to PV+ and -V(signal) , as...

  • Page 15: Parallel Function

    Iout 5. . 5 2 SHP-10K has the built-in active current sharing function and can be connected in parallel, up to 4 units, to provide higher output power as Non-Linear exhibited below : Non-Linear ◎ The power supplies should be paralleled using short and large diameter wiring and then connected to the load.

  • Page 16: Remote Control

    Remote Control Auxiliary Output The power supply can be turned ON-OFF by using the "Remote Built-in 12V/1A auxiliary output ● ● ON-OFF" function. CN86 CN86 CN53 CN53 SW81 SW81 PIN17 & 18 GND-AUX Figure 5 10 Figure PIN1 Remote ON-OFF PIN2 +5V-AUX PIN15 &...

  • Page 17: Communication Protocol

    6 1 2 PMBus Command List 6.Communication Protocol ◎The command list of the SHP-10K is shown in Table 6-2. It is There are two means to control the unit, analog signals and digital ● compliant with the standard protocol of PMBus Rev. 1.1.For communication.
  • Page 18 ◎Definition of Command BEh SYSTEM_CONFIG Bit 6 EEPER: EEPROM data access error Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 0 EEPROM ＝ data access normal High byte 1 EEPROM ＝ data access error Low byte OPERATION_INIT PM_CTRL Note: Low byte 1.When an EEPROM data access error occurs, the supply shuts down and Bit 0 PM_CTRL: PMBus Control Selection...

  • Page 19: Can Bus Communication

    Data field bytes Data Byte High Data Byte Low 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0 COMD low byte COMD high byte Data low byte Data high byte Read: Linear Data Format Data Bytes Y, N and the "real world" value is: The relation between Data field bytes X = Y 2...
  • Page 20 Table 6-4 Command Command Transaction # of data Description Code Name Type Bytes Command Command Transaction # of data Description Code Name Type Bytes System status 0x00C1 SYSTEM_STATUS ON/OFF control System configuration 0x00C2 SYSTEM_CONFIG 0x0000 OPERATION ON: 01h/OFF: 00h Note : The conversion of setting and reading values is defined as following: Output voltage set 0x0020 VOUT_SET...
  • Page 21 ◎MFR_DATE_B0B5 ( Bit 7 HI_TEMP：Internal high temperature protection 0x0086 ) is manufacture date (ASCII) 0＝Internal temperature normal MFR_DATE_B0B5 is 180101, meaning 2018/01/01 1＝Internal temperature abnormal Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Note: Unsupported settings displays with "0" 0x31 0x38 0x30...
  • Page 22 Bit 4:7 IOUT Factor：The Factor of DC current byte3: 0x = Output current relevant commands not supported Bit 0:3 IIN Factor：The Factor of AC input current 0x4=0.001 0x = AC input current relevant commands not supported 0x5=0.01 0x4=0.001 0x6=0.1 0x5=0.01 0x7=1.0 0x6=0.1 0x8=10...
  • Page 23 ◎SYSTEM_CONFIG (0x00C2)： 6 3 . Modbus Communication Interface Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 The device supports Modbus RTU with the master-salve principle. Low byte Users are able to read and write parameters of the device through OPERATION_INIT CAN_CTRL the protocol, including remote ON/OFF, output voltage/current Bit 0...
  • Page 24 6.3.3 Additional Address Definition 6.3.5 Data Field and Command Lists Additional address is the slave ID of the device. Each SHP-10K Data field provides additional information by the slave to unit should have their unique and own device address to complete the action specified by the function code(FC) in a communicate over the bus.
  • Page 25 ◎FAULT_STATUS (0x0040)： Register Command Function # of data Description address Name code Bytes Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 Low byte HI_TEMP OP_OFF AC_FAIL SHORT FAN FAIL Output voltage read value 0x0060 READ_VOUT 0x04 (format: value, F=0.01) 0 FAN FAIL ：Fan locked flag Output current read value 0x0061...
  • Page 26 ◎MFR_ID_B0B5 (0x0080 - 0x0082) is the first 6 codes of the Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 manufacturer's name (ASCII); MFR_ID_B6B11(0x0083 - 0x0085) is the 0xFE 0x69 0xFF 0xFF 0xFF 0xFF last 6 codes of the manufacturer's name (ASCII) ◎MFR_DATE_B0B5 (0x0091 -0x0093) is manufacture date (ASCII ) EX: manufacturer's name is MEANWELL →...
  • Page 27 ◎SCALING_FACTOR (0x00C0)： byte1: Bit 0:3 VIN Factor：The Factor of AC input voltage Bit7~Bit0 0x0=AC input relevant commands not supported byte4~5 Reserved 0x4=0.001 Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 0x5=0.01 byte3 Reserved IIN Factor 0x6=0.1 Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1...
  • Page 28 ◎SYSTEM_STATUS (0x00C3)： OPERATION_INIT：Pre-set value of power on operation command Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 0b00＝Power OFF, pre-set 0x00(OFF) INITIA- 0b01＝Power ON, pre-set0x01(ON) Low byte EEPER ADL_ON PFC OK DC_OK M S / LSTATE 0b10＝Pre-set is previous set value 0b11＝not used, reserved Bit 0: M/S：parallel mode status 0＝Current device is Slave...

  • Page 29: Value Range And Tolerance

    Request: Value range and tolerance 0x80 0x04 0x0 6 0x2FC5 (1)Display parameters 0x80: Slave ID 0 Model Display value range Tolerance 0x0 : Function code 4 (Read Analog Input Registers) 0x0060: The Data Address of the first register requested READ_VIN 340~530V ±10V 0x0001: he total number of registers requested ( read only 1 registers from...

  • Page 30: Protections And Trouble

    Note: 7.Protections and Trouble Shooting READ_IOUT will display ZERO amp when output current is less than values Protections in the table below. 7.1.1 Over Temperature Protection (OTP) and T Alarm Model Minimum readable Built-in thermal detection circuit, once the internal temperature 1.

  • Page 31: Trouble Shooting

    Over Voltage Protection ※ MEAN WELL possesses the right to adjust the content of this manual. When the output voltage is too high, the over-voltage protection Please refer to the latest version of manual on our website. circuit will be triggered. Repower on to restore after over-voltage https://www.meanwell.com...
